Sensors

Isabellenhütte IVT 3 Base

Current measurement sensor (ASIL C)
Current measurement up to 4,000A (Ext)
Temperature Measurement
Communication based on CAN 2.0B with DBC
Total accuracy of ±0.4% of rdg. +0.1A
Supply voltage 12V/24V**
Temperature range from -40°C to +125°C

Isabellenhütte IVT 3.0

Isabellenhütte IVT 3 Pro

Current measurement sensor (ASIL C)
3V or 6V measurement channels (ASIL B)
Active insulation monitoring (QM)
Temperature measurement
Current measurement up to 4,000A (Ext)
Voltage measurement up to 1,250V (Ext)
Temperature range from -40°C to +125°C

Isabellenhütte IVT 3.0 Pro

Core Sensors CS10 Series

Industrial pressure transducer
Pressure ranges from vacuum up to 45,000 PSI
Accuracy down to ≤ ±0.25% BFSL
Stability (1 year) of ≤ ±0.25% of FS
Overpressure of 2x minimum
Temperature range from -40°C to +85°C
Media Temperature from -40°C to +120°C

Core Sensors CS10

Core Sensors CS10T Series

Pressure and temperature measurement with independent outputs
Pressure ranges from 50 to 10,000 PSI
Multiple temperature ranges available
Accuracy down to ≤ ±0.25% BFSL
Stability (1 year) of ≤ ±0.25% of FS
Overpressure of 2x minimum

Core Sensors CS10-1

Core Sensors CS11 Series

Compact media isolated pressure sensor
Pressure ranges from 0-2 up to 2,000 PSI
Accuracy as low as ≤ ±0.25% BFSL
Stability of ≤ ±0.2% of FS (1 year)
Pressure cycles of 10 million
Overpressure of 2x minimum
Burst pressure of 5x or 4,000 PSI

Core Sensors CS11

Core Sensors CS12 Series

Submersible pressure transducer
Pressure ranges from 1 to 100 PSI
Accuracy down to ≤±0.25% BFSL
Stability (1 year) of ≤±0.25% of FS
Pressure cycles of 50 million
Overpressure of 2x minimum
Burst pressure of 5x or 500 PSI

Core Sensors CS12

Core Sensors CS14 Series

Wet/wet differential pressure transducer
Differential pressure ranges up to 300 PSI
Line pressure up to 500 PSI
Accuracy of ≤±0.25% BFSL at 25°C
Stability of ≤±0.25% of FS
Pressure cycles of 4 million
Overpressure of 2x or 500 PSI

Core Sensors CS14

Core Sensors CS15 Series

Non-Clogging submersible pressure transducer
Pressure ranges from 2 PSI to 50 PSI
Flush diaphragm prevents clogging
Hastelloy C276 diaphragm material
IP68 rated
Operating temperature of -40 to +85°C
Compensated temperatures from 0 to +55°C

Core Sensors CS15

Core Sensors CS20 Series

Industrial temperature transmitter
RTD sensor type, PT100, Class B
Media temperature range of -40°C up to +200°C *
Operating temperature range of -40°C up to +85°C
Total error at RT & FS of ≤±1%
Maximum pressure of 5,000 PSI
Amplified 4-20mA or 1-5V output signal

Core Sensors CS20

Core Sensors CS50 Series

Non-incendive pressure transducer
Pressure ranges from 50 PSI to 30,000 PSI
Accuracy of ≤±0.25% BFSL at 25°C
Stability of ≤±0.25% of FS
Pressure cycles of 100 million
Overpressure of 2x minimum
Burst pressure of 5x or 60,000 PSI

Core Sensors CS50

Core Sensors CS51 Series

Non-incendive low pressure transducer
Pressure ranges from 1 PSI up to 49 PSI
Temperature range from −20°C up to +80°C *
Accuracy of ≤±0.25% BFSL at 25°C **
Stability of ≤±0.25% of FS (1 year)
Pressure cycles of 100 million
Overpressure of 2x minimum

Core Sensors CS51

Core Sensors CS54 Series

Non-Incendive Differential Pressure Transducer
Differential pressure up to 50 PSI
Line pressure up to 500 PSI
Accuracy of ≤±0.25% BFSL / ≤±0.5% BFSL (2 PSI & below)
Overpressure of 2X or 500 PSI (whichever is less)
Temperature range −40°C to +80°C
Media temperature of -40 to +125°C

Core Sensors CS54

Core Sensors CS60 Series

Explosion-Proof Pressure Transducer
Pressure ranges from 50 PSI to 30,000 PSI
One piece diaphragm design – No internal O-rings or welds
Factory sealed stainless steel case – Withstands harsh environments
Accuracy of ≤±0.25% BFSL at 25°C (<10,000 PSI)
Pressure cycles of 100 million
Overpressure of 2x minimum

Core Sensors CS60

Core Sensors CS80 Series

Intrinsically safe pressure transducer
Pressure ranges available from 50 PSI up to 30,000 PSI
Temperature range −40°C to +85°C
Accuracy of ≤ ±0.25% BFSL
Burst pressure of 5x or 60,000 PSI whichever is less
Stability (1 year) of ≤ ±0.25% of FS
Pressure cycles of 100 million

Core Sensors CS80

Core Sensors CS81 Series

Intrinsically safe low pressure transducer
Pressure ranges from 1 PSI to 49 PSI
Accuracy of ≤±0.25% BFSL
Stability of ≤±0.25% of FS (1 year)
Pressure cycles of 100 million
Overpressure of 2x minimum
Burst pressure of 5x or 245 PSI

Core Sensors CS81

Core Sensors CS82 Series

Intrinsically safe submersible pressure transducer
Pressure ranges from 1 PSI up to 50 PSI
Accuracy of ≤±0.25% BFSL
Stability of ≤±0.25% of FS (1 year)
Pressure cycles of 50 million
Overpressure of 2x minimum
Burst pressure of 5x or 250 PSI

Core Sensors CS82

Isabellenhütte IVT 3 Base

Current Measurement Sensor

Current measurement sensor (ASIL C)
Current measurement up to 4,000A (Ext)
Temperature Measurement
Communication based on CAN 2.0B with DBC
Total accuracy of ±0.4% of rdg. +0.1A
Supply voltage 12V/24V**
Temperature range from -40°C to +125°C

Isabellenhütte IVT 3 Pro

Current & Voltage Measurement Sensor

Current measurement sensor (ASIL C)
3V or 6V measurement channels (ASIL B)
Active insulation monitoring (QM)
Temperature measurement
Current measurement up to 4,000A (Ext)
Voltage measurement up to 1,250V (Ext)
Temperature range from -40°C to +125°C

Core Sensors CS10 Series

Industrial Pressure Transducer

Industrial pressure transducer
Pressure ranges from vacuum up to 45,000 PSI
Accuracy down to ≤ ±0.25% BFSL
Stability (1 year) of ≤ ±0.25% of FS
Overpressure of 2x minimum
Temperature range from -40°C to +85°C
Media Temperature from -40°C to +120°C

Core Sensors CS10T Series

Dual Pressure and Temperature Transducer

Pressure and temperature measurement with independent outputs
Pressure ranges from 50 to 10,000 PSI
Multiple temperature ranges available
Accuracy down to ≤ ±0.25% BFSL
Stability (1 year) of ≤ ±0.25% of FS
Overpressure of 2x minimum

Core Sensors CS11 Series

Compact Media Isolated Pressure Sensor

Compact media isolated pressure sensor
Pressure ranges from 0-2 up to 2,000 PSI
Accuracy as low as ≤ ±0.25% BFSL
Stability of ≤ ±0.2% of FS (1 year)
Pressure cycles of 10 million
Overpressure of 2x minimum
Burst pressure of 5x or 4,000 PSI

Core Sensors CS12 Series

Submersible Level Sensor

Submersible pressure transducer
Pressure ranges from 1 to 100 PSI
Accuracy down to ≤±0.25% BFSL
Stability (1 year) of ≤±0.25% of FS
Pressure cycles of 50 million
Overpressure of 2x minimum
Burst pressure of 5x or 500 PSI

Core Sensors CS14 Series

Wet/Wet Differential Pressure Transducer

Wet/wet differential pressure transducer
Differential pressure ranges up to 300 PSI
Line pressure up to 500 PSI
Accuracy of ≤±0.25% BFSL at 25°C
Stability of ≤±0.25% of FS
Pressure cycles of 4 million
Overpressure of 2x or 500 PSI

Core Sensors CS15 Series

Non-Clogging Submersible Pressure Transducer

Non-Clogging submersible pressure transducer
Pressure ranges from 2 PSI to 50 PSI
Flush diaphragm prevents clogging
Hastelloy C276 diaphragm material
IP68 rated
Operating temperature of -40 to +85°C
Compensated temperatures from 0 to +55°C

Core Sensors CS20 Series

RTD Temperature Transmitter

Industrial temperature transmitter
RTD sensor type, PT100, Class B
Media temperature range of -40°C up to +200°C *
Operating temperature range of -40°C up to +85°C
Total error at RT & FS of ≤±1%
Maximum pressure of 5,000 PSI
Amplified 4-20mA or 1-5V output signal

Core Sensors CS50 Series

Non-Incendive Pressure Transducer

Non-incendive pressure transducer
Pressure ranges from 50 PSI to 30,000 PSI
Accuracy of ≤±0.25% BFSL at 25°C
Stability of ≤±0.25% of FS
Pressure cycles of 100 million
Overpressure of 2x minimum
Burst pressure of 5x or 60,000 PSI

Core Sensors CS51 Series

Non-Incendive Low Pressure Transducer

Non-incendive low pressure transducer
Pressure ranges from 1 PSI up to 49 PSI
Temperature range from −20°C up to +80°C *
Accuracy of ≤±0.25% BFSL at 25°C **
Stability of ≤±0.25% of FS (1 year)
Pressure cycles of 100 million
Overpressure of 2x minimum

Core Sensors CS54 Series

Non-Incendive Differential Pressure Transducer

Non-Incendive Differential Pressure Transducer
Differential pressure up to 50 PSI
Line pressure up to 500 PSI
Accuracy of ≤±0.25% BFSL / ≤±0.5% BFSL (2 PSI & below)
Overpressure of 2X or 500 PSI (whichever is less)
Temperature range −40°C to +80°C
Media temperature of -40 to +125°C

Core Sensors CS60 Series

Explosion-Proof Pressure Transducer

Explosion-Proof Pressure Transducer
Pressure ranges from 50 PSI to 30,000 PSI
One piece diaphragm design – No internal O-rings or welds
Factory sealed stainless steel case – Withstands harsh environments
Accuracy of ≤±0.25% BFSL at 25°C (<10,000 PSI)
Pressure cycles of 100 million
Overpressure of 2x minimum

Core Sensors CS80 Series

Intrinsically Safe Pressure Transducer

Intrinsically safe pressure transducer
Pressure ranges available from 50 PSI up to 30,000 PSI
Temperature range −40°C to +85°C
Accuracy of ≤ ±0.25% BFSL
Burst pressure of 5x or 60,000 PSI whichever is less
Stability (1 year) of ≤ ±0.25% of FS
Pressure cycles of 100 million

Core Sensors CS81 Series

Intrinsically Safe Low Pressure Transducer

Intrinsically safe low pressure transducer
Pressure ranges from 1 PSI to 49 PSI
Accuracy of ≤±0.25% BFSL
Stability of ≤±0.25% of FS (1 year)
Pressure cycles of 100 million
Overpressure of 2x minimum
Burst pressure of 5x or 245 PSI

Core Sensors CS82 Series

Intrinsically Safe Submersible Pressure Transducer

Intrinsically safe submersible pressure transducer
Pressure ranges from 1 PSI up to 50 PSI
Accuracy of ≤±0.25% BFSL
Stability of ≤±0.25% of FS (1 year)
Pressure cycles of 50 million
Overpressure of 2x minimum
Burst pressure of 5x or 250 PSI

Featured products

ICS-NH PTM-10 Miniature Pressure Temperature Transmitter

Combined pressure and temperature transmitter in miniature design
Pressure ranges from 0–30 psig up to 0–8,700 psig
Ratiometric pressure output 0.5–4.5 V @ 5 V supply
Integrated PT1000 2-wire temperature output
Operating temperature range −40 °C to +150 °C (approx.)
Stainless steel housing with multiple connection options

ICS-NH MPT6C Series Cryogenic Pressure Transmitter

Cryogenic pressure transmitter for extreme temperature applications
Pressure ranges from 2 bar to 2,000 bar
Operating temperature from −200 °C to +260 °C
Multiple output options including voltage, current and digital
Fully welded stainless steel construction
Vibration tested to DO-160 Cat. H and R

ICS-NH MPT6 Series

Miniature actively compensated pressure transmitter with 0 to 30 psi to 0 to 15,000 psi ranges and 5 to 32VDC supply. Offers voltage, current, bridge, I²C and SPI outputs with DO-160 Cat. H/R vibration testing

ICS-NH MPT4A Miniature Pressure Transmitter

Miniature pressure transmitter with extremely compact design
Pressure ranges from 0–30 psi up to 0–3,000 psi
Ratiometric output 0.5–4.5 V @ 5 V supply
Supply voltage 4.5–5.5 V DC
Fast response time 0.1 ms
Stainless steel construction with multiple connection options

Manufacturers

Looking for Sensors?

The below manufacturers are all of our authorised partners that produce Sensors or related products.

Coto Technology

Metis Engineering Ltd

Newtek Sensor Solutions

Stellar Technology

Sensors

We offer a broad selection of sensors from a number of different industry leading manufacturers. Many of our sensors are designed for use in a variety of industries including Automotive, Medical, Aerospace, Oil & Gas and other harsh environment applications. Our range of sensors available include:

Temperature Sensors
Pressure Sensors
Magnetic Sensors
Load Cells
Float & Flow Switches

From standard off-the-shelf products to customised sensors, we can work with you and our authorised partners to offer the right solution suited to your requirements.

Looking for that extended pressure range, greater temperature rating or a different connector fitting? Need something a little different from the standard products below? Contact us now with your requirement.
