RARA

  • RARA

RARA FRH 25C

  • Metal clad thick film resistor
  • Resistance range from 1kΩ to 2MΩ
  • Max power rating of 15W
  • Cement moulding within aluminium housing
  • Short time overload of 2 x power rating is 5 seconds
  • High stability at conventional power ratings
  • Temperature range of -55°C up to +250°C
  • Compliant
FRH25C
  • RARA

RARA FRH 50C

  • Metal clad thick film resistor
  • Resistance range from 1kΩ to 2MΩ
  • Max power rating of 25W
  • Cement moulding within aluminium housing
  • Short time overload of 2 x power rating is 5 seconds
  • High stability at conventional power ratings
  • Temperature range of -55°C up to +250°C
  • Compliant
RARA FRH 50C
  • RARA

RARA IRH60

RARA Aluminum Housed, Chassis Mount Resistor Model: IRH, IRV, ULH, ULV, ARH, ARV
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation resistance of 20MΩ minimum
  • Temperature range of -55°C up to +200°C
  • Extruded aluminium horizontal housing
  • Short time overload of 5 x power rating is 5 seconds
  • Compliant
RARA IRH60
  • RARA

RARA IRH80

RARA Aluminum Housed, Chassis Mount Resistor Model: IRH, IRV, ULH, ULV, ARH, ARV
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation resistance of 20MΩ minimum
  • Temperature range of -55°C up to +200°C
  • Extruded aluminium horizontal housing
  • Short time overload of 10 x power rating is 5 seconds
  • Compliant
RARA IRH80
  • RARA

RARA IRH100

RARA Aluminum Housed, Chassis Mount Resistor Model: IRH, IRV, ULH, ULV, ARH, ARV
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation resistance of 20MΩ minimum
  • Temperature range of -55°C up to +200°C
  • Extruded aluminium horizontal housing
  • Short time overload of 10 x power rating is 5 seconds
  • Compliant
RARA IRH100
  • RARA

RARA IRH120

RARA Aluminum Housed, Chassis Mount Resistor Model: IRH, IRV, ULH, ULV, ARH, ARV
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation resistance of 20MΩ minimum
  • Temperature range of -55°C up to +200°C
  • Extruded aluminium horizontal housing
  • Short time overload of 10 x power rating is 5 seconds
  • Compliant
RARA IRH120
  • RARA

RARA IRH150

RARA Aluminum Housed, Chassis Mount Resistor Model: IRH, IRV, ULH, ULV, ARH, ARV
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation resistance of 20MΩ minimum
  • Temperature range of -55°C up to +200°C
  • Extruded aluminium horizontal housing
  • Short time overload of 10 x power rating is 5 seconds
  • Compliant
RARA IRH150
  • RARA

RARA IRH200

RARA Aluminum Housed, Chassis Mount Resistor Model: IRH, IRV, ULH, ULV, ARH, ARV
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation resistance of 20MΩ minimum
  • Temperature range of -55°C up to +200°C
  • Extruded aluminium horizontal housing
  • Short time overload of 10 x power rating is 5 seconds
  • Compliant
RARA IRH200
  • RARA

RARA IRH300

RARA Aluminum Housed, Chassis Mount Resistor Model: IRH, IRV, ULH, ULV, ARH, ARV
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation resistance of 20MΩ minimum
  • Temperature range of -55°C up to +200°C
  • Extruded aluminium horizontal housing
  • Short time overload of 10 x power rating is 5 seconds
  • Compliant
RARA IRH300
  • RARA

RARA IRH400

RARA Aluminum Housed, Chassis Mount Resistor Model: IRH, IRV, ULH, ULV, ARH, ARV
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation resistance of 20MΩ minimum
  • Temperature range of -55°C up to +200°C
  • Extruded aluminium horizontal housing
  • Short time overload of 10 x power rating is 5 seconds
  • Compliant
RARA IRH400
  • RARA

RARA IRH500

RARA Aluminum Housed, Chassis Mount Resistor Model: IRH, IRV, ULH, ULV, ARH, ARV
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation resistance of 20MΩ minimum
  • Temperature range of -55°C up to +200°C
  • Extruded aluminium horizontal housing
  • Short time overload of 10 x power rating is 5 seconds
  • Compliant
RARA IRH500
  • RARA

RARA IRM600

  • Metal clad wire wound resistor
  • Resistance options from 0.1Ω up to 94Ω
  • Power rating of up to 600W (on a heat sink)
  • Tolerance options between ±1% and ±10.0%
  • TCR of +260 ppm/°C maximum
  • For UL Approval see the ULM Series
  • Compliant
RARA IRM600
  • RARA

RARA IRM800

  • Metal clad wire wound resistor
  • Resistance options from 0.1Ω up to 112Ω
  • Power rating of up to 800W (on a heat sink)
  • Tolerance options between ±1% and ±10.0%
  • TCR of +260 ppm/°C maximum
  • For UL Approval see the ULM
  • Compliant
RARA IRM800
  • RARA

RARA IRM1000

  • Metal clad wire wound resistor
  • Resistance options from 0.1Ω up to 150Ω
  • Power rating of up to 1000W (on a heat sink)
  • Tolerance options between ±1% and ±10.0%
  • TCR of +260 ppm/°C maximum
  • For UL Approval see the ULM
  • Compliant
RARA IRM1000
  • RARA

RARA IRM1200

  • Metal clad wire wound resistor
  • Resistance options from 0.1Ω up to 160Ω
  • Power rating of up to 1200W (on a heat sink)
  • Tolerance options between ±1% and ±10.0%
  • TCR of +260 ppm/°C maximum
  • For UL Approval see the ULM
  • Compliant
RARA IRM1200
  • RARA

RARA IRM1600

  • Metal clad wire wound resistor
  • Resistance options from 0.3Ω up to 88Ω
  • Power rating of up to 570W (free air)
  • Tolerance options between ±1% and ±10.0%
  • TCR of +260 ppm/°C maximum
  • For UL Approval see the ULM
  • Compliant
RARA IRM1600

RARA FRH 25C

High Power Metal Clad Resistors
  • Metal clad thick film resistor
  • Resistance range from 1kΩ to 2MΩ
  • Max power rating of 15W
  • Cement moulding within… Read More

RARA FRH 50C

High Power Metal Clad Resistors
  • Metal clad thick film resistor
  • Resistance range from 1kΩ to 2MΩ
  • Max power rating of 25W
  • Cement moulding within… Read More

RARA IRH60

Metal Clad Wire Wound Resistors
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation… Read More

RARA IRH80

Metal Clad Wire Wound Resistors
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation… Read More

RARA IRH100

Metal Clad Wire Wound Resistors
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation… Read More

RARA IRH120

Metal Clad Wire Wound Resistors
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation… Read More

RARA IRH150

Metal Clad Wire Wound Resistors
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation… Read More

RARA IRH200

Metal Clad Wire Wound Resistors
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation… Read More

RARA IRH300

Metal Clad Wire Wound Resistors
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation… Read More

RARA IRH400

Metal Clad Wire Wound Resistors
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation… Read More

RARA IRH500

Metal Clad Wire Wound Resistors
  • Metal clad wire wound resistor
  • Option of flying leads (tab terminals are standard)
  • Inductive or non-inductive design
  • Insulation… Read More

RARA IRM600

Metal Clad Wire Wound Resistors
  • Metal clad wire wound resistor
  • Resistance options from 0.1Ω up to 94Ω
  • Power rating of up to 600W (on… Read More

RARA IRM800

Metal Clad Wire Wound Resistors
  • Metal clad wire wound resistor
  • Resistance options from 0.1Ω up to 112Ω
  • Power rating of up to 800W (on… Read More

RARA IRM1000

Metal Clad Wire Wound Resistors
  • Metal clad wire wound resistor
  • Resistance options from 0.1Ω up to 150Ω
  • Power rating of up to 1000W (on… Read More

RARA IRM1200

Metal Clad Wire Wound Resistors
  • Metal clad wire wound resistor
  • Resistance options from 0.1Ω up to 160Ω
  • Power rating of up to 1200W (on… Read More

RARA IRM1600

Metal Clad Wire Wound Resistors
  • Metal clad wire wound resistor
  • Resistance options from 0.3Ω up to 88Ω
  • Power rating of up to 570W (free… Read More
Exclusive Partner

About RARA

RARA’s has been in business since 1989 with the vision to be the most competitive industrial resistor manufacturer in the world.  With a combined effort from all the RARA teams and our international agents, we have made solid, steady progress as a high power resistor manufacturer.

We are committed to the production of high quality products, an ongoing R&D program, unparalleled customer service, a conscientious attitude toward our environment and a positive workplace for our employees.

RARA will continue to offer state-of-the-art products at reasonable costs and maintain it’s program of product development to best suit our customers. RARA’s newly recognized R&D center provides custom design service and technical support.

RARA would like to give customers a “ONE-STOP SOLUTION” with all kinds of resistive products. For their official website, please visit www.raraohm.com
