SMD High Temperature Class I Capacitors

High Temperature Class I SMD Capacitor
Capacitance from 0.1pF to 330nF
Voltages from 10V to 2000V
Ultra stable temperature compensating classe I ceramic up to 250°C
Tested in accordance to CECC 32100 and AEC-Q200
Custom voltage, package size, capacitance value on reques

Metis Engineering Air Wise

Air Wise is a CAN based sensor that can measure absolute pressure, air temperature, Nitrous Oxides (NOx), Volatile Organic Compounds (VOCs), Carbon Dioxide (CO2), absolute air water content, relative humidity, dew point temperature, impact shock.

Absolute Pressure: 0.3 to 1.2 Bar
Air Temperature: -40°C to +125°C
Relative Humidity: 0% to 100%
Dew Point Temperature: 0 to 100°C
Accelerometer Range: -24 to +24g

Datasheet

Metis Engineering Cell Guard

Cell Guard is a CAN-based environmental sensor for use with Battery Packs in Energy Storage Systems and Electric Vehicles. It measures absolute pressure, air temperature, VOCs, absolute humidity, relative humidity, dew point temperature, and shock load and duration.

For quick desktop analysis, use alongside the Nano Development Kit.

Datasheet

Metis Engineering H Guard

H Guard is a CAN based sensor that can measure absolute pressure, air temperature, H2 (Hydrogen), absolute air water content, relative humidity, dew point temperature and 3 axis acceleration.

Absolute Pressure: 0.3 to 1.2 Bar
Air Temperature: -40°C to +125°C
Relative Humidity: 0% to 100%
Dew Point Temperature: 0 to 100°C
Accelerometer Range: -24 to +24g

Datasheet

VPG TLA Series

Conformally coated thin film precision resistor
Resistance range from 100kΩ to 5MΩ
Tolerance from ±0.05% to ±1%
TCR of ±5 ppm/°C or ±10 ppm/°C
Power rating of 0.125W (at +70°C)
Temperature Range from -25°C up to +155°C

Datasheet

VPG TLC Series

Conformally coated thin film precision resistor
Resistance range from 200kΩ to 10MΩ
Tolerance from ±0.02% to ±1%
TCR of ±5 ppm/°C or ±10 ppm/°C
Power rating of 0.25W (at +70°C)
Temperature Range from -25°C up to +155°C

Datasheet

Isabellenhütte ICD series

Shunt-based Current Sensor
Current range up to ±500A
Communication based on CANbus 2.0A/B
Input voltage tolerance 5.5V to 26V
Temperature range from -40°C to +105°C

Datasheet

Isabellenhütte IVT 3 Base

Current measurement sensor (ASIL C)
Current measurement up to 4,000A (Ext)
Temperature Measurement
Communication based on CAN 2.0B with DBC
Total accuracy of ±0.4% of rdg. +0.1A
Supply voltage 12V/24V**
Temperature range from -40°C to +125°C

Datasheet

Isabellenhütte IVT 3 Pro

Current measurement sensor (ASIL C)
3V or 6V measurement channels (ASIL B)
Active insulation monitoring (QM)
Temperature measurement
Current measurement up to 4,000A (Ext)
Voltage measurement up to 1,250V (Ext)
Temperature range from -40°C to +125°C

Datasheet

General Resistance 8G16 Econistor Series

Wirewound axial leaded precision resistor
Resistance range from 1Ω up to 699kΩ
Tight tolerances of ±0.01% and ±0.1%
TCR of ±5 ppm/°C
Power rating from 0.33W (8G16D model)
Temperature range from -55°C up to +160°C

Datasheet

General Resistance GG102 Squaristor Series

Wirewound radial leaded precision resistor
Resistance range from 10Ω up to 200kΩ
Tight tolerances of ±0.01% and ±0.1%
TCR of ±5 ppm/°C
Power rating up to 0.3W (GG102D Model)
Temperature range from -55°C up to +160°C

Datasheet

General Resistance 5E10 Mini-Ohm Series

Wirewound axial leaded precision resistor
Resistance range from 10Ω up to 200kΩ
Tight tolerances of ±0.01% and ±0.1%
TCR of ±5 ppm/°C
Power rating up to 0.2W (5E10D model)
Temperature range from -55°C up to +160°C

Datasheet

General Resistance 8E16 Econistor Series

Wirewound axial leaded precision resistor
Resistance range from 1Ω up to 699kΩ
Tight tolerances of ±0.01% and ±0.1%
TCR of ±5 ppm/°C
Power rating up to 0.33W (8E16D model)
Temperature range from -55°C up to +160°C

Datasheet

Caddock MK227 Series

Precision power film radial leaded through-hole resistor
Non-inductive with expanded resistance range
Maximum working voltage of 200V
Compact rectangular package with standard lead spacing
Constructed with Caddock’s Micronox® resistance films fired onto a solid ceramic substrate
Extended life stability is typically better than 0.1% per 1,000 hours
Temperature range from -40°C up to +150°C

Datasheet

Caddock MK232 Series

Precision power film radial leaded through-hole resistor
Non-inductive with expanded resistance range
Maximum working voltage of 200V
Compact rectangular package with standard lead spacing
Constructed with Caddock’s Micronox® resistance films fired onto a solid ceramic substrate
Extended life stability is typically better than 0.1% per 1,000 hours
Temperature range from -40°C up to +150°C

Datasheet

Caddock MK727 Series

Precision power film radial leaded through-hole resistor
Non-inductive with expanded resistance range
Maximum working voltage of 400V
Compact rectangular package with standard lead spacing
Constructed with Caddock’s Micronox® resistance films fired onto a solid ceramic substrate
Extended life stability is typically better than 0.1% per 1,000 hours
Temperature range from -40°C up to +150°C

Datasheet
