Military & Defense

Selection of ‘EEE’ approved surface-mount current sensing resistors by Isabellenhütte and ultra-precision resistors from Vishay Foil Resistors
Selection of Military grade surface mount, high voltage chip resistors from Ohmcraft.

Cissoid’s range of semiconductors designed especially for high temperature applications and harsh environments.

‘EEE’ approved pressure sensors from Emerson Paine™.

Robust and accurate general purpose load cells from Lord Sensing Stellar Technology.

Thermocouple foil temperature sensors by RdF.

Military & Defense

Caddock USF240 Series

Ultra-stable radial leaded film through-hole resistors
Constructed with two selected USF300 series resistors bonded back to back for parallel connection on the PCB
Maximum working voltage of 300V
Ceramic package provides cool operation
Utilising Caddock’s proprietary resistance film systems
Available in standard resistance values most commonly used in precision analog design
Zero nominal TCR
Temperature range from -40°C up to +85°C

Datasheet

Caddock USF270 Series

Ultra-stable radial leaded film through-hole resistors
Constructed with two selected USF300 series resistors bonded back to back for parallel connection on the PCB
Maximum working voltage of 1.4kV
Ceramic package provides cool operation
Utilising Caddock’s proprietary resistance film systems
Available in standard resistance values most commonly used in precision analog design
Zero nominal TCR
Temperature range from -40°C up to +85°C

Datasheet

Caddock USF271 Series

Ultra-stable radial leaded film through-hole resistors
Constructed with two selected USF300 series resistors bonded back to back for parallel connection on the PCB
Maximum working voltage of 2.5kV
Ceramic package provides cool operation
Utilising Caddock’s proprietary resistance film systems
Available in standard resistance values most commonly used in precision analog design
Zero nominal TCR
Temperature range from -40°C up to +85°C

Datasheet

Caddock USF340 Series

Ultra-stable radial leaded film through-hole resistors
Maximum working voltage of 300V
Ceramic package provides cool operation
Utilising Caddock’s proprietary resistance film systems
Available in standard resistance values most commonly used in precision analog design
Zero nominal TCR
Temperature range from -40°C up to +85°C

Datasheet

Caddock USF370 Series

Ultra-stable radial leaded film through-hole resistors
Maximum working voltage of 1.4kV
Ceramic package provides cool operation
Utilising Caddock’s proprietary resistance film systems
Available in standard resistance values most commonly used in precision analog design
Zero nominal TCR
Temperature range from -40°C up to +85°C

Datasheet

Caddock USF371 Series

Ultra-stable radial leaded film through-hole resistors
Maximum working voltage of 2.5kV
Ceramic package provides cool operation
Utilising Caddock’s proprietary resistance film systems
Available in standard resistance values most commonly used in precision analog design
Zero nominal TCR
Temperature range from -40°C up to +85°C

Datasheet

Caddock USFS Series

Ultra-stable radial leaded film through-hole resistor sets
Sets are available with either 3 or 5 selected USF300 series resistors (model dependent)
Voltage coefficient as low as 0.005 ppm/V per resistor set (model dependent)
Ceramic package provides cool operation
Utilising Caddock’s proprietary resistance film systems
Available in 30MΩ, 50MΩ and 100MΩ sets
Multiple USFS selected resistor sets can be used in series to achieve higher total resistances and higher voltage ratings

Datasheet

Exxelia Ohmcraft HVCD 3512

High-voltage surface-mount chip divider
Voltage rating up to 2000V
Resistance range from 40MΩ to 10GΩ
Ratio tolerances as tight as ±1%
TCR tracking as low as ±25 ppm/°C
Power rating of 100mW

Datasheet

Exxelia Ohmcraft MCH 0402

Military Grade High Voltage SMD Resistors
Resistance range from 10kΩ to 1GΩ
Tolerances from ±1% to ±20%
TCR of ±50 ppm/°C, ±100 ppm/°C or ±200 ppm/°C
Power rating of 0.04W
Voltage rating of 150V
Temperature range from -55°C to +150°C

Datasheet

Exxelia Ohmcraft MCH 0603

Military Grade High Voltage SMD Resistors
Resistance range from 10kΩ to 50GΩ
Tolerances from ±0.5% to ±20%
TCR of ±50 ppm/°C, ±100 ppm/°C or ±200 ppm/°C
Power rating of 0.06W
Voltage rating of 4000V
Temperature range from -55°C to +150°C

Datasheet

Exxelia Ohmcraft MCH 0805

Military Grade High Voltage SMD Resistors
Resistance range from 10kΩ to 50GΩ
Tolerances from ±0.5% to ±20%
TCR of ±50 ppm/°C, ±100 ppm/°C or ±200 ppm/°C
Power rating of 0.2W
Voltage rating of 600V
Temperature range from -55°C to +150°C

Datasheet

Exxelia Ohmcraft MCH 1206

Military Grade High Voltage SMD Resistors
Resistance range from 10kΩ to 50GΩ
Tolerances from ±0.1% to ±20%
TCR from ±25 ppm/°C to ±200 ppm/°C
Power rating of 0.33W
Voltage rating of 1.5kV
Temperature range from -55°C to +150°C

Datasheet

Exxelia Ohmcraft MCH 2010

Military Grade High Voltage SMD Resistors
Resistance range from 10kΩ to 50GΩ
Tolerances from ±0.1% to ±20%
TCR from ±25 ppm/°C to ±200 ppm/°C
Power rating of 1W
Voltage rating of 2kV
Temperature range from -55°C to +150°C

Datasheet

Exxelia Ohmcraft MCH 2512

Military Grade High Voltage SMD Resistors
Resistance range from 10kΩ to 50GΩ
Tolerances from ±0.1% to ±20%
TCR from ±25 ppm/°C to ±200 ppm/°C
Power rating of 2W
Voltage rating of 3kV
Temperature range from -55°C to +150°C

Datasheet

Exxelia Ohmcraft MCH 3512

Military Grade High Voltage SMD Resistors
Resistance range from 10kΩ to 50GΩ
Tolerances from ±0.1% to ±20%
TCR from ±25 ppm/°C to ±200 ppm/°C
Power rating of 2W
Voltage rating of 3.5kV
Temperature range from -55°C to +150°C

Datasheet

Exxelia Ohmcraft MCH 4020

Military Grade High Voltage SMD Resistors
Resistance range from 10kΩ to 50GΩ
Tolerances from ±0.1% to ±20%
TCR from ±25 ppm/°C to ±200 ppm/°C
Power rating of 2W
Voltage rating of 4kV
Temperature range from -55°C to +150°C

Datasheet
