Isabellenhütte AZ-H2 Series

  • Isabellenhütte

Product Features

  • Current sensing resistor
  • 4-terminal through-hole design
  • Resistance range from 0.002Ω to 1Ω
  • Tolerance of ±0.1% or ±1%
  • TCR of <±3 ppm/°C or <±10 ppm/°C (+20°C to +60°C)
  • Power rating 10W on a suitable heat sink
  • Temperature range from -55°C to +140°C

Applications

  • Scientific Instrumentation
  • Test and Measurement
  • Compliant

Description

The AZ-H2 current sensing precision resistor series from Isabellenhütte offers 4-terminal through-hole connection technology for current sensing applications with very low TCR. Designed for easy heat sink mounting, the Kelvin connections on this resistor allow high precision measurements even with a low resistance range of 2mΩ to 1Ω. The AZ-H2 series from Isabellenhütte has low inductance and has high pulse power handling capabilities.

  • 4-terminal current sense resistor
  • Through-hole design
  • Resistance range from 0.002Ω to 1Ω
  • Tolerance options available of ±0.1% and ±1%
  • TCR of <±3 ppm/°C (+20°C to +60°C) & TCR of <±10 ppm/°C (+20°C to +60°C)
  • Temperature range from -55°C to +140°C
  • Power rating of 10W on a suitable heat sink
  • Power rating of 3W in free air
  • Inductance of <10nH
  • Maximum constant current of 70A (0.002Ω)
  • Designed for easy heat sink mounting
  • Low self-heating



Typical applications for the AZ-H2 current sense resistor series include:

  • Measurement equipment
  • Reference resistors in laboratories
  • Current sources
  • Laboratory power supplies

Isabellenhütte AZ-H2 Series Specification Table

AttributesValue
Resistance value2mΩ to 1Ω
Tolerance±0.1% / ±1%
TCR ±3 ppm/°C, ±10 ppm/°C (20-60°C)
Temperature range-55°C to +140°C
Power rating3W (free air) / 10W (on a suitable heatsink)
Thermal resistance to ambient<15°C/W (Rth)
Thermal resistance to aluminium substrate<3°C/W (Rthi)
Dielectric withstanding voltage500V AC/DC
Inductance<10nH
Stability (deviation after 2000hrs)<0.1% (Tᴋ = 80°C with heatsink) / <0.2% (Tᴋ = 95°C with heatsink)
Tᴋ = Terminal Temperature

* Please visit the Ordering Info tab or contact us for further details



Isabellenhütte is one of the world’s leading suppliers of high-quality precision and power resistors. They produce these low-resistance resistors for a variety of applications such as the ones above. Isabellenhütte & Rhopoint Components are your ideal partners when it comes to achieving the best possible measurement results in the smallest spaces. Please visit www.isabellenhuette.de for more information.

Specifications

Dimensions 38 × 5 × 25.5 mm
Product Type

Temperature Coefficient

,

Minimum Resistance

Series / Model

Maximum Resistance

Tolerance

,

Power Rating

,

Resistance Value

, , , ,

Current Rating

Package / Size

Temperature Range (°C)

Isabellenhütte AZ-H2 Series Ordering Info

The AZ-H2 resistor series is available with various options including standard resistance values and tolerances. The information below gives an example of the part numbering system used for these resistors and the standard options available.

Below is an example of the part number break down for the AZ-H2 resistor series:

AZ-H2 Series Ordering Info

Isabellenhütte AZ-H2 Series – Available Resistance Values and Tolerances


Resistance Value Part Number Value 0.1% Tolerance 1% Tolerance
0.002Ω R002
0.005Ω R005
0.01Ω R010
0.1Ω R100
1Ω 1R00
