  • Through-hole RJ45 jack with transformer
  • 750 plugging cycles
  • Gold over nickel contact surface
  • Twin port
  • Black in colour
  • Temperature range of −40°C to +85°C
  • EAC approved and UL listed
  • UL

Applications

  • Compliant

Description

The RJ45G1 R12D 3.3E4YG/YG RL jack with transformer from the Weidmüller Omnimate data range, offers twin magnetic transmitter sockets for gigabit applications (1000 base-T) with integrated compensation, which actively counteracts inductive and capacitive couplings as well as saving space on the PCB. This RJ45 twin jack with transformer connector by Weidmüller feature 8 poles with an outgoing elbow of 90° and extended temperature range of −40°C to +85°C.

  • RJ45 jack
  • Mounting onto PCB via through-hole (THT) THR solder connection
  • Transmission rate 1000MBit/s
  • Outgoing elbow of 90°
  • Shield surface being nickel-plated
  • Twin port
  • 4 LEDs with a yellow and green LED in each port
  • EAC approved and UL listed
  • 8 poles
  • Contact surface of gold over nickel
  • Dielectric strength of ≥1000VDC
  • Temperature range −40°C to +85°C

The Weidmüller RJ45 jack series is characterised by its compactness and simplicity. It is used predominantly in:

  • Horizontal wiring
  • Wiring workstations

For further information regarding the specifications, please see the datasheet on the Technical Library tab.


Specifications

Weight 0.00000 kg
Dimensions 31.20 × 21.50 × 13.60 mm
Shielding

Series / Model

LED

Number of Poles

Transmission Rate

Conductor Outlet Direction

RoHS Compliant Product – Weidmüller

This product is available fully compliant to the RoHS EU directive 2011/65/EU.
