PCB terminal connector with 2 row female plug

Weidmüller B2CF 3.50/180 Series

  • PCB terminal connector with 2 row female plug
  • Rated current for minimum number of poles 13.4A (IEC) and 9.5A (UL)
  • Dimensions of L1 3.5mm to 76.5mm (depending on the number of poles required)
  • Push in spring connection with integrated push buttons for opening the terminal point
  • Clamping range from 0.14mm² to 1.5mm²
  • Temperature range −50°C up to +120°C
  • CSA and UL 1059 approved, IEC listed
  • Compliant

The B2CF 3.50/180 female 2 row plug PCB plug in connector series from Weidmüller’s Omnimate signal range has been designed with a conductor outlet direction of 180°. They have a 3.5mm pitch and a choice from 4 up to 46 poles. The B2CF 3.50/180 series from Weidmüller have a push in spring connection with integrated push buttons for opening the terminal point. These connectors have an operating temperature range of −50°C up to +120°C .

  • 2 Row female plug in connector
  • Push in spring connection with integrated push buttons for opening the terminal point
  • Number of poles available from 4 to 46
  • Clamping range from 0.14 mm² to 1.5mm²
  • Pitch of 3.5mm
  • Conductor outlet direction of 180°
  • CSA and UL 1059 approved, IEC listed
  • Dimmensions for L1 from 3.5mm to 76.5mm depending on the number of poles required
  • Rated current for minimum number of poles 13.4A (IEC) and 9.5A (UL)
  • Orange in colour (additional colours available on request)
  • Packaged in box
  • Temperature range −50°C up to +120°C


The below table gives the specifications of the Weidmüller B2CF 3.50/180 PCB connector series:

Weidmüller B2CF 3.50/180 Specifications

Please see the relevant datasheet in the technical library for the exact specification

Specifications

Weight 0.00000 kg
Dimensions 0.00 x 0.00 x 0.00mm
Colour

Orange

Conductor Outlet Direction

180°

Number of Poles

4, 6, 8, 10, 12, 14, 16, 18, 20, 22, 24, 26, 28, 30, 32, 34, 36, 38, 40, 42, 44, 46

Pitch

3.5mm

Series / Model

Termination / Connection

Push-in Spring Clamp

Product Variations

SKUNumber of Poles
Weidmüller B2CF 3.50/180 Series10
Weidmüller B2CF 3.50/180 Series12
Weidmüller B2CF 3.50/180 Series14
Weidmüller B2CF 3.50/180 Series16
Weidmüller B2CF 3.50/180 Series18
Weidmüller B2CF 3.50/180 Series20
Weidmüller B2CF 3.50/180 Series22
Weidmüller B2CF 3.50/180 Series24
Weidmüller B2CF 3.50/180 Series26
Weidmüller B2CF 3.50/180 Series28
Weidmüller B2CF 3.50/180 Series30
Weidmüller B2CF 3.50/180 Series32
Weidmüller B2CF 3.50/180 Series34
Weidmüller B2CF 3.50/180 Series36
Weidmüller B2CF 3.50/180 Series38
Weidmüller B2CF 3.50/180 Series4
Weidmüller B2CF 3.50/180 Series40
Weidmüller B2CF 3.50/180 Series42
Weidmüller B2CF 3.50/180 Series44
Weidmüller B2CF 3.50/180 Series46
Weidmüller B2CF 3.50/180 Series6
Weidmüller B2CF 3.50/180 Series8

RoHS Compliant Product – Weidmüller

This product is available fully compliant to the RoHS EU directive 2011/65/EU.

Weidmüller B2CF 3.50/180 SN OR BX Technical Library

We are pleased to provide you with a range of additional content including product datasheets, case studies, white papers and application notes for your reference. Please see below for the latest content available:





DOCUMENTATION
4 Pole – Weidmüller Omnimate Signal B2CF 3.50 04 180 SN OR BX PCB connector datasheet
6 Pole – Weidmüller Omnimate Signal B2CF 3.50 06 180 SN OR BX PCB connector datasheet
8 Pole – Weidmüller Omnimate Signal B2CF 3.50 08 180 SN OR BX PCB connector datasheet
10 Pole – Weidmüller Omnimate Signal B2CF 3.50 10 180 SN OR BX PCB connector datasheet
12 pole – Weidmüller Omnimate Signal B2CF 3.50 12 180 SN OR BX PCB connector datasheet
14 Pole – Weidmüller Omnimate Signal B2CF 3.50 14 180 SN OR BX PCB connector datasheet
16 Pole – Weidmüller Omnimate Signal B2CF 3.50 16 180 SN OR BX PCB connector datasheet
18 Pole – Weidmüller Omnimate Signal B2CF 3.50 18 180 SN OR BX PCB connector datasheet
20 pole – Weidmüller Omnimate Signal B2CF 3.50 20 180 SN OR BX PCB connector datasheet
22 Pole – Weidmüller Omnimate Signal B2CF 3.50 22 180 SN OR BX PCB connector datasheet
24 Pole – Weidmüller Omnimate Signal B2CF 3.50 24 180 SN OR BX PCB connector datasheet
26 Pole – Weidmüller Omnimate Signal B2CF 3.50 26 180 SN OR BX PCB connector datasheet
28 pole – Weidmüller Omnimate Signal B2CF 3.50 28 180 SN OR BX PCB connector datasheet
30 Pole – Weidmüller Omnimate Signal B2CF 3.50 30 180 SN OR BX PCB connector datasheet
32 Pole – Weidmüller Omnimate Signal B2CF 3.50 32 180 SN OR BX PCB connector datasheet
34 Pole – Weidmüller Omnimate Signal B2CF 3.50 34 180 SN OR BX PCB connector datasheet
36 pole – Weidmüller Omnimate Signal B2CF 3.50 36 180 SN OR BX PCB connector datasheet
38 Pole – Weidmüller Omnimate Signal B2CF 3.50 30 180 SN OR BX PCB connector datasheet
40 Pole – Weidmüller Omnimate Signal B2CF 3.50 32 180 SN OR BX PCB connector datasheet
42 Pole – Weidmüller Omnimate Signal B2CF 3.50 34 180 SN OR BX PCB connector datasheet
44 pole – Weidmüller Omnimate Signal B2CF 3.50 36 180 SN OR BX PCB connector datasheet
46 pole – Weidmüller Omnimate Signal B2CF 3.50 36 180 SN OR BX PCB connector datasheet
