Stellar Technology RDE915 Series

  • Stellar Technology

Product Features

  • Compact, high capacity rod end compression and tension load cell
  • Environmentally sealed
  • Low defection
  • Shock and vibration resistant
  • High strength tool steel
  • 5 point calibration record traceable to NIST (0, 50%, 100%, 50%, 0)
  • Temperature effect on zero ±0.005% FSO/°F
  • Temperature effect on span ±0.005% Reading/°F
  • Zero balance ±1% FSO

Applications

The RDE915 compact, high capacity rod end load cell series from Stellar Technology, offers maximum load range from 2.5k lbs to 25k lbs with an accuracy of ±0.25% FSO. These load cells are designed for both in-line tension and compression force applications. The RDE915 from Stellar Technology are constructed from high strength tool steel with bonded foil strain gauged force sensors being environmentally sealed, are compact in size and provide reliable performance. Hysteresis of 0.15% FSO and an operating temperature range of −65°F (-53.89°C) to +250°F (+121.11°C).

  • Compact, high capacity rod end load cell
  • Low defection
  • Environmentally sealed
  • Maximum load ranges of 5k lbs, 10k lbs, 15k lbs and 25k lbs
  • Temperature range −65°F (-53.89°C) to +250°F (+121.11°C)
  • Accuracy of ±0.25% FSO and linearity of ±0.25% FSO
  • Electrical output of 2mV/V nominal
  • Hysteresis of 0.15% FSO
  • Temperature effect on zero of ±0.002% FSO/°F
  • Temperature effect on span of ±0.002% reading/°F
  • Zero balance of ±1% FSO
  • Shock and vibration resistant
  • Each unit comes with a 5 point calibration record traceable to NIST



The RDE915 series from Stellar Technology are used in many in-line tension applications such as actuator testing aircraft and automotive component testing and materials testing. Full optional features include:

  • Metric versions
  • Special full scale ranges
  • Special calibration
  • Dual or triple bridges
  • Temperature range −40°F (-40°C) to +400°F (+204.44°C)

Potential markets for the Stellar Technology RDE905 series include:

  • Defence systems, test and measurement
  • Alternative energy, industrial automation
  • Medical and pharmaceutical, power generation
  • Oil and gas, process
  • test and measurement
  • Transportation and automotive
