Caddock TG Series

Precision high voltage axial leaded through-hole resistor
Resistance range: 25 kΩ to 1,000 MΩ
Temperature coefficient: ±25 ppm/°C from -55°C to +125°C
Load life stability: 0.25% per 1,000 hours at +125°C
Resistance tolerance options: ±0.1%, ±0.25%, ±0.5%, ±1%
Maximum continuous operating voltage up to 30 kV
-15 series increases maximum voltage by 60%

Cissoid CMT-PLA3SB12340A

Silicon Carbide (SiC) MOSFET Intelligent Power Module
3-phase inverter with anti-parallel diodes
Drain-to-source Breakdown Voltage of 1200V
Max Continuous Current of 340A/260A at Tc=25°C/90°C
Low On Resistance of 3.25 mΩ typical
Junction Temperature: -40°C to +175°C

Cissoid CXT-PLA3BG07820R IGBT Power Module

Max Collector Voltage: 750V
Implemented Collector Current: 820A
DC Collector Current @ TF=80°C: 450A
Low Saturation Voltage (VCE(sat)= 1.15V @ IC=450A, Tj=25°C) (VCE(sat)= 1.25V @ IC=450A, Tj=175°C)
Low Switching Energy (Eon= 16.8mJ at Tj=25°C) (Eoff= 15.7mJ Tj=25°C)
Operating range -40 to +175°C (Tj)

Core Sensors CS-SM Series

Steel mill pressure transducer
Pressures up to 350 Bar
Accuracy down to ≤±0.25% BFSL
Pressure cycles of >100 million
Burst pressure of 10X or 20,000 PSI (whichever is less)
IP69 protection against high pressure washdown
Integral snubber protects against pressure transients

Core Sensors CS10 Series

Industrial pressure transducer
Pressure ranges from vacuum up to 45,000 PSI
Accuracy down to ≤ ±0.25% BFSL
Stability (1 year) of ≤ ±0.25% of FS
Overpressure of 2x minimum
Temperature range from -40°C to +85°C
Media Temperature from -40°C to +120°C

Core Sensors CS10T Series

Pressure and temperature measurement with independent outputs
Pressure ranges from 50 to 10,000 PSI
Multiple temperature ranges available
Accuracy down to ≤ ±0.25% BFSL
Stability (1 year) of ≤ ±0.25% of FS
Overpressure of 2x minimum

Core Sensors CS11 Series

Compact media isolated pressure sensor
Pressure ranges from 0-2 up to 2,000 PSI
Accuracy as low as ≤ ±0.25% BFSL
Stability of ≤ ±0.2% of FS (1 year)
Pressure cycles of 10 million
Overpressure of 2x minimum
Burst pressure of 5x or 4,000 PSI

Core Sensors CS12 Series

Submersible pressure transducer
Pressure ranges from 1 to 100 PSI
Accuracy down to ≤±0.25% BFSL
Stability (1 year) of ≤±0.25% of FS
Pressure cycles of 50 million
Overpressure of 2x minimum
Burst pressure of 5x or 500 PSI

Core Sensors CS14 Series

Wet/wet differential pressure transducer
Differential pressure ranges up to 300 PSI
Line pressure up to 500 PSI
Accuracy of ≤±0.25% BFSL at 25°C
Stability of ≤±0.25% of FS
Pressure cycles of 4 million
Overpressure of 2x or 500 PSI

Core Sensors CS15 Series

Non-Clogging submersible pressure transducer
Pressure ranges from 2 PSI to 50 PSI
Flush diaphragm prevents clogging
Hastelloy C276 diaphragm material
IP68 rated
Operating temperature of -40 to +85°C
Compensated temperatures from 0 to +55°C

Core Sensors CS20 Series

Industrial temperature transmitter
RTD sensor type, PT100, Class B
Media temperature range of -40°C up to +200°C *
Operating temperature range of -40°C up to +85°C
Total error at RT & FS of ≤±1%
Maximum pressure of 5,000 PSI
Amplified 4-20mA or 1-5V output signal

Core Sensors CS50 Series

Non-incendive pressure transducer
Pressure ranges from 50 PSI to 30,000 PSI
Accuracy of ≤±0.25% BFSL at 25°C
Stability of ≤±0.25% of FS
Pressure cycles of 100 million
Overpressure of 2x minimum
Burst pressure of 5x or 60,000 PSI

Core Sensors CS51 Series

Non-incendive low pressure transducer
Pressure ranges from 1 PSI up to 49 PSI
Temperature range from −20°C up to +80°C *
Accuracy of ≤±0.25% BFSL at 25°C **
Stability of ≤±0.25% of FS (1 year)
Pressure cycles of 100 million
Overpressure of 2x minimum

Core Sensors CS54 Series

Non-Incendive Differential Pressure Transducer
Differential pressure up to 50 PSI
Line pressure up to 500 PSI
Accuracy of ≤±0.25% BFSL / ≤±0.5% BFSL (2 PSI & below)
Overpressure of 2X or 500 PSI (whichever is less)
Temperature range −40°C to +80°C
Media temperature of -40 to +125°C

Core Sensors CS60 Series

Explosion-Proof Pressure Transducer
Pressure ranges from 50 PSI to 30,000 PSI
One piece diaphragm design – No internal O-rings or welds
Factory sealed stainless steel case – Withstands harsh environments
Accuracy of ≤±0.25% BFSL at 25°C (<10,000 PSI)
Pressure cycles of 100 million
Overpressure of 2x minimum

Core Sensors CS80 Series

Intrinsically safe pressure transducer
Pressure ranges available from 50 PSI up to 30,000 PSI
Temperature range −40°C to +85°C
Accuracy of ≤ ±0.25% BFSL
Burst pressure of 5x or 60,000 PSI whichever is less
Stability (1 year) of ≤ ±0.25% of FS
Pressure cycles of 100 million

Caddock TG Series

Precision high voltage axial leaded through-hole resistor
Resistance range: 25 kΩ to 1,000 MΩ
Temperature coefficient: ±25 ppm/°C from -55°C to +125°C
Load life stability: 0.25% per 1,000 hours at +125°C
Resistance tolerance options: ±0.1%, ±0.25%, ±0.5%, ±1%
Maximum continuous operating voltage up to 30 kV
-15 series increases maximum voltage by 60%

Cissoid CMT-PLA3SB12340A

Silicon Carbide (SiC) MOSFET Intelligent Power Module
3-phase inverter with anti-parallel diodes
Drain-to-source Breakdown Voltage of 1200V
Max Continuous Current of 340A/260A at Tc=25°C/90°C
Low On Resistance of 3.25 mΩ typical
Junction Temperature: -40°C to +175°C

Cissoid CXT-PLA3BG07820R IGBT Power Module

Max Collector Voltage: 750V
Implemented Collector Current: 820A
DC Collector Current @ TF=80°C: 450A
Low Saturation Voltage (VCE(sat)= 1.15V @ IC=450A, Tj=25°C) (VCE(sat)= 1.25V @ IC=450A, Tj=175°C)
Low Switching Energy (Eon= 16.8mJ at Tj=25°C) (Eoff= 15.7mJ Tj=25°C)
Operating range -40 to +175°C (Tj)

Core Sensors CS-SM Series

Steel mill pressure transducer
Pressures up to 350 Bar
Accuracy down to ≤±0.25% BFSL
Pressure cycles of >100 million
Burst pressure of 10X or 20,000 PSI (whichever is less)
IP69 protection against high pressure washdown
Integral snubber protects against pressure transients

Core Sensors CS10 Series

Industrial pressure transducer
Pressure ranges from vacuum up to 45,000 PSI
Accuracy down to ≤ ±0.25% BFSL
Stability (1 year) of ≤ ±0.25% of FS
Overpressure of 2x minimum
Temperature range from -40°C to +85°C
Media Temperature from -40°C to +120°C

Core Sensors CS10T Series

Pressure and temperature measurement with independent outputs
Pressure ranges from 50 to 10,000 PSI
Multiple temperature ranges available
Accuracy down to ≤ ±0.25% BFSL
Stability (1 year) of ≤ ±0.25% of FS
Overpressure of 2x minimum

Core Sensors CS11 Series

Compact media isolated pressure sensor
Pressure ranges from 0-2 up to 2,000 PSI
Accuracy as low as ≤ ±0.25% BFSL
Stability of ≤ ±0.2% of FS (1 year)
Pressure cycles of 10 million
Overpressure of 2x minimum
Burst pressure of 5x or 4,000 PSI

Core Sensors CS12 Series

Submersible pressure transducer
Pressure ranges from 1 to 100 PSI
Accuracy down to ≤±0.25% BFSL
Stability (1 year) of ≤±0.25% of FS
Pressure cycles of 50 million
Overpressure of 2x minimum
Burst pressure of 5x or 500 PSI

Core Sensors CS14 Series

Wet/wet differential pressure transducer
Differential pressure ranges up to 300 PSI
Line pressure up to 500 PSI
Accuracy of ≤±0.25% BFSL at 25°C
Stability of ≤±0.25% of FS
Pressure cycles of 4 million
Overpressure of 2x or 500 PSI

Core Sensors CS15 Series

Non-Clogging submersible pressure transducer
Pressure ranges from 2 PSI to 50 PSI
Flush diaphragm prevents clogging
Hastelloy C276 diaphragm material
IP68 rated
Operating temperature of -40 to +85°C
Compensated temperatures from 0 to +55°C

Core Sensors CS20 Series

Industrial temperature transmitter
RTD sensor type, PT100, Class B
Media temperature range of -40°C up to +200°C *
Operating temperature range of -40°C up to +85°C
Total error at RT & FS of ≤±1%
Maximum pressure of 5,000 PSI
Amplified 4-20mA or 1-5V output signal

Core Sensors CS50 Series

Non-incendive pressure transducer
Pressure ranges from 50 PSI to 30,000 PSI
Accuracy of ≤±0.25% BFSL at 25°C
Stability of ≤±0.25% of FS
Pressure cycles of 100 million
Overpressure of 2x minimum
Burst pressure of 5x or 60,000 PSI

Core Sensors CS51 Series

Non-incendive low pressure transducer
Pressure ranges from 1 PSI up to 49 PSI
Temperature range from −20°C up to +80°C *
Accuracy of ≤±0.25% BFSL at 25°C **
Stability of ≤±0.25% of FS (1 year)
Pressure cycles of 100 million
Overpressure of 2x minimum

Core Sensors CS54 Series

Non-Incendive Differential Pressure Transducer
Differential pressure up to 50 PSI
Line pressure up to 500 PSI
Accuracy of ≤±0.25% BFSL / ≤±0.5% BFSL (2 PSI & below)
Overpressure of 2X or 500 PSI (whichever is less)
Temperature range −40°C to +80°C
Media temperature of -40 to +125°C

Core Sensors CS60 Series

Explosion-Proof Pressure Transducer
Pressure ranges from 50 PSI to 30,000 PSI
One piece diaphragm design – No internal O-rings or welds
Factory sealed stainless steel case – Withstands harsh environments
Accuracy of ≤±0.25% BFSL at 25°C (<10,000 PSI)
Pressure cycles of 100 million
Overpressure of 2x minimum

Core Sensors CS80 Series

Intrinsically safe pressure transducer
Pressure ranges available from 50 PSI up to 30,000 PSI
Temperature range −40°C to +85°C
Accuracy of ≤ ±0.25% BFSL
Burst pressure of 5x or 60,000 PSI whichever is less
Stability (1 year) of ≤ ±0.25% of FS
Pressure cycles of 100 million
