SRT Microcéramique

SRT Microcéramique Radial Capacitor Dipped High Voltage

High voltage radial dipped capacitors
Capacitance from 0.4pF to 47µF
TCR options from ±30ppm/°C (NP0) to ±15% (X7R)
Voltages from 1kV to 15kV
IR 25°C/Un ≥10⁵MΩ or 1000Ω-Farad whichever is less *
Dielectrics: NP0, N2T, BX, 2C1, X7R
Operating temperatures from -55°C to +125°C

Add to Compare

Datasheet

SRT Microcéramique Low Voltage High Capacitance X7R Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 47µF
TCR of ±15% with 0Vdc applied
Voltages from 4V to 100V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X7R
Operating temperatures of -55°C to +125°C **

Add to Compare

Datasheet

SRT Microcéramique Low Voltage High Capacitance X5R Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 330µF
TCR of ±15% with 0Vdc applied
Voltages from 4V to 50V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X5R
Operating temperatures of -55°C, + 85°C

Add to Compare

Datasheet

SRT Microcéramique Low Voltage High Capacitance X6S Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 330µF
TCR of ±22% with 0Vdc applied
Voltages from 2.5V to 50V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X6S
Operating temperatures of -55°C, + 105°C

Add to Compare

Datasheet

SRT Microcéramique Low Voltage High Capacitance X7S Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 100µF
TCR of ±22% with 0Vdc applied
Voltages from 4V to 100V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X7S
Operating temperatures of -55°C to +125°C

Add to Compare

Datasheet

SRT Microcéramique Low Voltage High Capacitance X7T Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 100µF
TCR of +22% -33% with 0Vdc applied
Voltages from 2.5V to 100V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X7T
Operating temperatures of -55°C, + 125°C

Add to Compare

Datasheet

SRT Microcéramique SMD Extended Range Low Voltage Capacitors

SMD Low Voltage Capacitors (Extended Range)
Capacitance up to 220 µF
Voltages from 6.3V to 2000V
Operating temperature:
- NP0, X7R: -55°C to +125°C
- X5R: -55°C to +85°C
Tested in accordance with CECC 32100 and AEC-Q200

Add to Compare

Datasheet

SRT Microcéramique SMD Low Inductance Class II Capacitors

Low Inductance Class II Capacitor
Capacitance from 1.0 nF to 1.5 µF
Voltages from 6.3 V to 50 V
Operating temperatures of -55°C to +125°C
Inverted geometry reduces the ESL up to 60% to standard MLCC
Tested in accordance with CECC 32100 and AEC-Q200

Add to Compare

Datasheet

SRT Microcéramique SMD Low Voltage Class I Capacitors

Low Voltage Class I SMD Capacitor
Capacitance from 0.1 pF to 820 nF
TCR of ± 30ppm with 0Vdc applied
Voltages from 10V to 1000V
Operating temperatures of -55°C to +125°C
Tested in accordance to CECC 32100 and AEC-Q200

Add to Compare

Datasheet

SRT Microcéramique SMD Low Voltage Class II Capacitors

Low Voltage Class II SMD Capacitor
Capacitance from 2.2 pF to 47 µF
TCR of ± 15% with 0Vdc applied (X7R) / +15% -25% at rated voltage (BX)
Voltages from 10V to 1000V
Operating temperatures of -55°C to +125°C
Tested in accordance to CECC 32100 and AEC-Q200

Add to Compare

Datasheet

SRT Microcéramique SMD Low Voltage N2T Capacitors

Low Voltage N2T SMD Capacitor
Capacitance from 0.3 pF to 1.2 µF
TCR of -2200 ± 350 ppm/°C with 0Vdc applied
Voltages from 10V to 1000V
Operating temperatures of -55°C to +125°C
All PME SMD available in non magnetic termination

Add to Compare

Datasheet

SRT Microcéramique Chip Capacitors with Negative TC

NP0 (C0G) Chip ceramic capacitor with negative TC
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor under 10.10^-4 at 1V_rms and 1kH (or 1MHz)
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

Add to Compare

SRT Microcéramique High Frequency Capacitor Series

MLCC Capacitor for RF and Microwave communication
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor under 5.10^-4 at 1V_rms and 1MHz for values ≤ 1000pF and under 5.10^-4 at 1V_rms and 1KHz for values > 1000pF
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

Add to Compare

SRT Microcéramique High Power Low Frequency Capacitor Series

MLCC high power, low capacitance variation with voltage capacitors
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor under 10.10^-4 at 1V_rms and 1kHz (or 1MHz)
Insulation resistance under 20000 MOhm or 500 Ohm-Farad at 25°C under 500V
Dielectric strength test performed per method 103 of EIA 198-2-E

Add to Compare

SRT Microcéramique High Temperature NP0 Capacitor Series

High Temperature, ultra stable MLCC Capacitor
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor under 10.10^-4 at 1V_rms and 1kHz (or 1MHz)
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

Add to Compare

SRT Microcéramique High Temperature X7R Capacitor Series

High Temperature MLCC Capacitor
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor up to 0.025
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

Add to Compare

SRT Microcéramique Radial Capacitor Dipped High Voltage

High voltage radial dipped capacitors
Capacitance from 0.4pF to 47µF
TCR options from ±30ppm/°C (NP0) to ±15% (X7R)
Voltages from 1kV to 15kV
IR 25°C/Un ≥10⁵MΩ or 1000Ω-Farad whichever is less *
Dielectrics: NP0, N2T, BX, 2C1, X7R
Operating temperatures from -55°C to +125°C

SRT Microcéramique Low Voltage High Capacitance X7R Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 47µF
TCR of ±15% with 0Vdc applied
Voltages from 4V to 100V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X7R
Operating temperatures of -55°C to +125°C **

SRT Microcéramique Low Voltage High Capacitance X5R Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 330µF
TCR of ±15% with 0Vdc applied
Voltages from 4V to 50V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X5R
Operating temperatures of -55°C, + 85°C

SRT Microcéramique Low Voltage High Capacitance X6S Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 330µF
TCR of ±22% with 0Vdc applied
Voltages from 2.5V to 50V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X6S
Operating temperatures of -55°C, + 105°C

SRT Microcéramique Low Voltage High Capacitance X7S Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 100µF
TCR of ±22% with 0Vdc applied
Voltages from 4V to 100V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X7S
Operating temperatures of -55°C to +125°C

SRT Microcéramique Low Voltage High Capacitance X7T Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 100µF
TCR of +22% -33% with 0Vdc applied
Voltages from 2.5V to 100V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X7T
Operating temperatures of -55°C, + 125°C

SRT Microcéramique SMD Extended Range Low Voltage Capacitors

SMD Low Voltage Capacitors (Extended Range)
Capacitance up to 220 µF
Voltages from 6.3V to 2000V
Operating temperature:
- NP0, X7R: -55°C to +125°C
- X5R: -55°C to +85°C
Tested in accordance with CECC 32100 and AEC-Q200

SRT Microcéramique SMD Low Inductance Class II Capacitors

Low Inductance Class II Capacitor
Capacitance from 1.0 nF to 1.5 µF
Voltages from 6.3 V to 50 V
Operating temperatures of -55°C to +125°C
Inverted geometry reduces the ESL up to 60% to standard MLCC
Tested in accordance with CECC 32100 and AEC-Q200

SRT Microcéramique SMD Low Voltage Class I Capacitors

Low Voltage Class I SMD Capacitor
Capacitance from 0.1 pF to 820 nF
TCR of ± 30ppm with 0Vdc applied
Voltages from 10V to 1000V
Operating temperatures of -55°C to +125°C
Tested in accordance to CECC 32100 and AEC-Q200

SRT Microcéramique SMD Low Voltage Class II Capacitors

Low Voltage Class II SMD Capacitor
Capacitance from 2.2 pF to 47 µF
TCR of ± 15% with 0Vdc applied (X7R) / +15% -25% at rated voltage (BX)
Voltages from 10V to 1000V
Operating temperatures of -55°C to +125°C
Tested in accordance to CECC 32100 and AEC-Q200

SRT Microcéramique SMD Low Voltage N2T Capacitors

Low Voltage N2T SMD Capacitor
Capacitance from 0.3 pF to 1.2 µF
TCR of -2200 ± 350 ppm/°C with 0Vdc applied
Voltages from 10V to 1000V
Operating temperatures of -55°C to +125°C
All PME SMD available in non magnetic termination

SRT Microcéramique Chip Capacitors with Negative TC

NP0 (C0G) Chip ceramic capacitor with negative TC
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor under 10.10^-4 at 1V_rms and 1kH (or 1MHz)
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

SRT Microcéramique High Frequency Capacitor Series

MLCC Capacitor for RF and Microwave communication
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor under 5.10^-4 at 1V_rms and 1MHz for values ≤ 1000pF and under 5.10^-4 at 1V_rms and 1KHz for values > 1000pF
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

SRT Microcéramique High Power Low Frequency Capacitor Series

MLCC high power, low capacitance variation with voltage capacitors
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor under 10.10^-4 at 1V_rms and 1kHz (or 1MHz)
Insulation resistance under 20000 MOhm or 500 Ohm-Farad at 25°C under 500V
Dielectric strength test performed per method 103 of EIA 198-2-E

SRT Microcéramique High Temperature NP0 Capacitor Series

High Temperature, ultra stable MLCC Capacitor
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor under 10.10^-4 at 1V_rms and 1kHz (or 1MHz)
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

SRT Microcéramique High Temperature X7R Capacitor Series

High Temperature MLCC Capacitor
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor up to 0.025
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

About SRT Microcéramique

SRT-Microcéramique is a French manufacturer of ceramic capacitors ( MLCC) present on the European market for more than 30 years.
In the permanent listening of our customers, our objective is to supply condensers in short times for any applications, including the most demanding.
Quality is our first objective. A process of qualification and follow-up of processes with clean means is in place.
We are particularly involved in the applications of severe environments that are the high temperature, the high voltage, the high frequencies. These components are used in domains demanding as medical, aeronautics, defense and oil.
Besides ceramic capacitors, we also supply electromagnetic filters.
We are strongly involved in a process of innovation in the domains of condensers and filters which allow her to answer customers’ specific demands.

For their official website, please visit srt-microceramique.com

Supporting Manufacturer Information

SRT Microcéramique Product Catalogue

Audio

Energy

EV & Automotive

Healthcare & Medical

Industrial

Military & Defense

Oil & Gas

Renewables

Space

SRT Microcéramique

About SRT Microcéramique

Supporting Manufacturer Information
