SRT Microcéramique SMD Low Voltage N2T Capacitors

SRT Microcéramique’s SMD Low Voltage N2T capacitors are high-performance multilayer ceramic capacitors (MLCCs) designed to deliver exceptional stability and power handling in compact surface-mount packages. Engineered with N2T dielectric material, these capacitors exhibit characteristics close to Class I stability while offering high capacitance values, making them ideal for applications requiring precise timing, filtering, and pulse discharge capabilities.

These capacitors are available in capacitance values ranging from 0.3 pF to 1.2 µF, and voltage ratings from 10 V up to 1000 V, offering engineers flexibility in circuit design for both low and moderate voltage conditions. The capacitors operate reliably in a wide temperature range of -55°C to +125°C, with select dielectric types offering temperature stability suitable for automotive, industrial, and consumer-grade electronics.

Thanks to their high volumetric efficiency, these capacitors offer greater capacitance in smaller footprints, supporting the growing demand for miniaturization in modern electronics. In addition, they feature stable performance characteristics under varying voltage and frequency conditions, ensuring consistent operation in applications such as power supply smoothing, battery management systems, and audio circuits.

Key Features for SMD Low Voltage Class II Capacitor:

• Capacitance range: 0.3 pF to 1.2 µF
• Voltage ratings: 10V to 1000V
• Dielectric Class: 1.5 (N2T)
• Operating temperature: -55°C to +125°C
• Temperature Coefficient: -2200 ± 350 ppm/°C with 0Vdc applied
• No piezo electric effect, high current pulse discharge
• Available in stack or radial
• Wide range of termination
• All PME SMD available in non magnetic termination

* Custom voltage, package size, capacitance value on request.

Typical Applications for the SMD Low Voltage N2T Capacitor:

• Timing Circuits: Providing precise capacitance for accurate timing functions.
• Filtering: Effective in noise suppression and signal smoothing in power supplies and signal lines.
• Pulse Discharge: Capable of handling high current pulses without piezoelectric effects, suitable for applications like defibrillators or pulsed lasers.

SRT Microcéramique , based in France, is a leading manufacturer of multilayer ceramic capacitors. Known for its precision and reliability, SRT Microcéramique supplies high-performance components to industries with demanding requirements. Visit SRT Microceramique for more information.
