Resistor series

  • Resi

Resi APLR Series

High energy anti-pulse resistor with up to 1000J capability, 6W power rating and non-inductive design for high-voltage and transient applications.
  • Compliant
APLR1000XXXXXSX
  • Resi

Resi HVLR Series

High voltage thick film resistor with up to 48kV operating voltage, 1kΩ to 1GΩ resistance range and axial mounting for reliable HV circuit design.
  • Compliant
HVLRXXXXXXXXXKX
  • Resi

Resi MMFR Series

A high‑stability precision metal film resistor with 10Ω to 1MΩ range, 0.25W–1W rating, ultra-tight ±0.05% tolerance, low ±5 ppm/°C TCR, and durable through-hole, moisture-resistant construction.
  • Compliant
MMFRXXXXXXXXXVX
  • Resi

Resi PTFR Series

Precision thin film chip resistor with 10Ω to 5.1MΩ range, tolerance down to ±0.01% and TCR as low as ±5ppm/℃ for high-stability SMD circuits.
  • Compliant
PTFRXXXXXXXXXXX
  • Resi

Resi PZFR Series

Precision foil chip resistor with 5Ω to 125kΩ range, ±0.01% tolerance and ±2 ppm TCR for ultra-stable SMD circuit designs.
  • Compliant
PZFRXXXXXXXXXXX
  • Resi

Resi SOTC0227 Series

High power thick film resistor with up to 300W rating, wide resistance range and robust SMD design for load, regulation and high-energy applications.
  • Compliant
SOTC0227XXXXXKX
  • VPG Foil Resistors

VPG PE Series

  • Ultra-precision 4 terminal shunt resistor
  • Resistance range form 0.5Ω to 500Ω
  • Tolerance from ±0.01% to ±5%
  • TCR of ±2.5 ppm/°C, ±5 ppm/°C or ±15 ppm/°C
  • Power rating of upto 10W (on a heat sink at 70°C)
  • Temperature range from -55°C up to +155°C
  • Compliant
VPG PE Series
  • VPG Foil Resistors

VPG PSB Series

  • Ultra-precision power shunt resistor
  • Resistance range form 0.001Ω to 1Ω
  • Tolerance of ±0.1%, ±0.5% or 1%
  • TCR of ±5 ppm/°C or ±15 ppm/°C
  • Power rating of upto 40W (on a heat sink at 25°C)
  • Temperature range from -55°C up to +85°C
  • Compliant
VPG PSB Series
  • VPG Foil Resistors

VPG RBD Series

  • Ultra-precision current sensing resistor
  • Resistance range form 0.01Ω to 1Ω
  • Tolerance from ±0.5% to ±5%
  • TCR of ±10 ppm/°C or ±25 ppm/°C
  • Power rating of 0.5W (at 70°C)
  • Temperature range from -65°C to +155°C
  • Compliant
VPG RBD Series
  • VPG Foil Resistors

VPG RBF Series

  • Ultra-precision current sensing resistor
  • Resistance range form 0.01Ω to 1Ω
  • Tolerance from ±0.5% to ±5%
  • TCR of ±10 ppm/°C or ±25 ppm/°C
  • Power rating of 1W (at 70°C)
  • Temperature range from -65°C to +155°C
  • Compliant
VPG RBF Series
  • VPG Foil Resistors

VPG RBH Series

  • Ultra-precision current sensing resistor
  • Resistance range form 0.01Ω to 0.1Ω
  • Tolerance from ±0.5% to ±5%
  • TCR of ±10 ppm/°C or ±25 ppm/°C
  • Power rating of 1.5W (at 70°C)
  • Temperature range from -65°C to +155°C
  • Compliant
VPG RBH Series
  • VPG Foil Resistors

VPG RWA Series

  • High precision wraparound resistor
  • Resistance range form 100Ω to 5kΩ
  • Tolerance of ±005% or ±0.1%
  • TCR of ±5 ppm/°C
  • Power rating of 0.1W (at 70°C)
  • Temperature range from -65°C to +155°C
  • Compliant
VPG RWA Series
  • VPG Foil Resistors

VPG RWB Series

  • High precision wraparound resistor
  • Resistance range form 10Ω to 10kΩ
  • Tolerance from ±0.02% to ±0.5%
  • TCR of ±2 ppm/°C, ±5 ppm/°C or ±10 ppm/°C
  • Power rating of 0.2W (at 70°C)
  • Temperature range from -65°C to +155°C
  • Compliant
VPG RWB Series
  • VPG Foil Resistors

VPG RWC Series

  • High precision wraparound resistor
  • Resistance range form 5Ω to 130kΩ
  • Tolerance from ±0.01% to ±0.5%
  • TCR of ±2 ppm/°C, ±5 ppm/°C or ±10 ppm/°C
  • Power rating of 0.3W (at 70°C)
  • Temperature range from -65°C to +155°C
  • Compliant
VPG RWC Series
  • VPG Foil Resistors

VPG SC Series

  • Ultra precision resistor network
  • Resistance range form 30Ω to 120kΩ
  • Tolerance from ±0.01% to ±0.5%
  • TCR of ±5 ppm/°C
  • Power rating of 1.5W (at 70°C)
  • Temperature range from -65°C to +155°C
  • Compliant
VPG SC Series
  • VPG Foil Resistors

VPG SE Series

  • Conformally coated precision resistor network
  • Resistance range 30Ω and 120kΩ
  • Tolerance from ±0.05% to ±0.1% available
  • TCR of ±5 ppm/°C
  • Power rating of 1W (at +70°C)
  • Temperature range from -25°C to +125°C
  • Compliant
VPG SE Series

Resi APLR Series

High energy anti-pulse resistor
High energy anti-pulse resistor with up to 1000J capability, 6W power rating and non-inductive design for high-voltage and transient applications.

Resi HVLR Series

Planar Non-inductive Power Resistor
High voltage thick film resistor with up to 48kV operating voltage, 1kΩ to 1GΩ resistance range and axial mounting for reliable HV circuit design.

Resi MMFR Series

Precision Metal Film Molded Resistor
A high‑stability precision metal film resistor with 10Ω to 1MΩ range, 0.25W–1W rating, ultra-tight ±0.05% tolerance, low ±5 ppm/°C TCR, and durable through-hole, moisture-resistant construction.

Resi PTFR Series

High-Stability Precision Thin Film Chip Resistor
Precision thin film chip resistor with 10Ω to 5.1MΩ range, tolerance down to ±0.01% and TCR as low as ±5ppm/℃ for high-stability SMD circuits.

Resi PZFR Series

Precision Foil Chip Resistor
Precision foil chip resistor with 5Ω to 125kΩ range, ±0.01% tolerance and ±2 ppm TCR for ultra-stable SMD circuit designs.

Resi SOTC0227 Series

Planar Non-inductive Power Resistor
High power thick film resistor with up to 300W rating, wide resistance range and robust SMD design for load, regulation and high-energy applications.

VPG PE Series

PE Ultra Precision Through Hole Power Resistor
  • Ultra-precision 4 terminal shunt resistor
  • Resistance range form 0.5Ω to 500Ω
  • Tolerance from ±0.01% to ±5%
  • TCR of ±2.5 ppm/°C, ±5 ppm/°C or ±15 ppm/°C
  • Power rating of upto 10W (on a heat sink at 70°C)
  • Temperature range from -55°C up to +155°C

VPG PSB Series

PSB Ultra Precision Power Shunt Resistor
  • Ultra-precision power shunt resistor
  • Resistance range form 0.001Ω to 1Ω
  • Tolerance of ±0.1%, ±0.5% or 1%
  • TCR of ±5 ppm/°C or ±15 ppm/°C
  • Power rating of upto 40W (on a heat sink at 25°C)
  • Temperature range from -55°C up to +85°C

VPG RBD Series

RBD Ultra Precision Flip Chip Current Sense Resistor
  • Ultra-precision current sensing resistor
  • Resistance range form 0.01Ω to 1Ω
  • Tolerance from ±0.5% to ±5%
  • TCR of ±10 ppm/°C or ±25 ppm/°C
  • Power rating of 0.5W (at 70°C)
  • Temperature range from -65°C to +155°C

VPG RBF Series

RBF Ultra Precision Flip Chip Current Sense Resistor
  • Ultra-precision current sensing resistor
  • Resistance range form 0.01Ω to 1Ω
  • Tolerance from ±0.5% to ±5%
  • TCR of ±10 ppm/°C or ±25 ppm/°C
  • Power rating of 1W (at 70°C)
  • Temperature range from -65°C to +155°C

VPG RBH Series

RBH Ultra Precision Flip Chip Current Sense Resistor
  • Ultra-precision current sensing resistor
  • Resistance range form 0.01Ω to 0.1Ω
  • Tolerance from ±0.5% to ±5%
  • TCR of ±10 ppm/°C or ±25 ppm/°C
  • Power rating of 1.5W (at 70°C)
  • Temperature range from -65°C to +155°C

VPG RWA Series

RWA Surface Mount Precision Resistor
  • High precision wraparound resistor
  • Resistance range form 100Ω to 5kΩ
  • Tolerance of ±005% or ±0.1%
  • TCR of ±5 ppm/°C
  • Power rating of 0.1W (at 70°C)
  • Temperature range from -65°C to +155°C

VPG RWB Series

RWB Surface Mount Precision Resistor
  • High precision wraparound resistor
  • Resistance range form 10Ω to 10kΩ
  • Tolerance from ±0.02% to ±0.5%
  • TCR of ±2 ppm/°C, ±5 ppm/°C or ±10 ppm/°C
  • Power rating of 0.2W (at 70°C)
  • Temperature range from -65°C to +155°C

VPG RWC Series

RWC Surface Mount Precision Resistor
  • High precision wraparound resistor
  • Resistance range form 5Ω to 130kΩ
  • Tolerance from ±0.01% to ±0.5%
  • TCR of ±2 ppm/°C, ±5 ppm/°C or ±10 ppm/°C
  • Power rating of 0.3W (at 70°C)
  • Temperature range from -65°C to +155°C

VPG SC Series

SC Through Hole Resistor Network
  • Ultra precision resistor network
  • Resistance range form 30Ω to 120kΩ
  • Tolerance from ±0.01% to ±0.5%
  • TCR of ±5 ppm/°C
  • Power rating of 1.5W (at 70°C)
  • Temperature range from -65°C to +155°C

VPG SE Series

SE Through Hole Resistor Network
  • Conformally coated precision resistor network
  • Resistance range 30Ω and 120kΩ
  • Tolerance from ±0.05% to ±0.1% available
  • TCR of ±5 ppm/°C
  • Power rating of 1W (at +70°C)
  • Temperature range from -25°C to +125°C
