Product Features

  • World’s first Smart TMR Magnetometer
  • Detecting magnets over 50mm away with superior in-plane sensitivity
  • 24 bit output resolution
  • Sample rate of 300 samples per second
  • Internal temperature compensating
  • Range of programmable features
  • Robust EDS protection, suitable for harsh environments

Applications

  • Automotive
  • Compliant

Description

The SM324-10E smart magnetometer from NVE is designed to provide ultra-precise magnetic field measurements while detecting magnets even over 50mm away. It utilises Tunneling Magnetoresonance (TMR) technology, which is superior compared to the traditional Hall-effect devices in terms of in-plane sensitivity, precision (±0.3% accuracy), speed (300 samples per second) and noise levels. The I2C interface works as data as well as programming interface; the programmable values include magnetic thresholds, sensor offset, temperature values, user-defined memory and other values. The digital signal also allows for application-specific calibration; the calibration coefficient is stored in internal non-volatile memory. The SM324-10E is capable of withstanding harsh environments, including those in automotive applications, due to their robust ESD protection, and is available in ultraminiature TDFN6 package (2.5×2.5mm footprint).

  • Smart TMR Magnetometer
  • Magnetic field operating range of 0 to ±20 Oe
  • 24bit output resolution
  • Accuracy as low as ±0.3% at 25° (±1% across the temperature range)
  • Sample rate of 300 samples per second
  • Temperature range of −40°C to +125°C
  • 1.68V to 3.6V supply
  • Programmable features include offset and gain correction, I2C address and thresholds
  • Sophisticated digital signal processing
  • Ultraminiature TDFN6 package

Typical applications for the SM324-10E series include:

  • Proximity sensing
  • Noncontact current sensing
  • Robotics
  • Automotive applications
  • Internet of Things (IoT) end nodes

The below table gives the full specifications of the NVE SM324-10E smart TMR magnetometer:

NVE SM324-10E Specifications

Specifications

Weight 0.05500 kg
Dimensions 2.50 × 2.50 × 0.80 mm
Accuracy

Series / Model
Temperature Range (°C)

Supply Voltage

Package / Size

RoHS Compliant Product – NVE

This product is available fully compliant to the RoHS EU directive 2011/65/EU.
