0805 series

SRT Microcéramique Low Voltage High Capacitance X7R Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 47µF
TCR of ±15% with 0Vdc applied
Voltages from 4V to 100V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X7R
Operating temperatures of -55°C to +125°C **

SRT Microcéramique Low Voltage High Capacitance X5R Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 330µF
TCR of ±15% with 0Vdc applied
Voltages from 4V to 50V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X5R
Operating temperatures of -55°C, + 85°C

SRT Microcéramique Low Voltage High Capacitance X6S Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 330µF
TCR of ±22% with 0Vdc applied
Voltages from 2.5V to 50V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X6S
Operating temperatures of -55°C, + 105°C

SRT Microcéramique Low Voltage High Capacitance X7S Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 100µF
TCR of ±22% with 0Vdc applied
Voltages from 4V to 100V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X7S
Operating temperatures of -55°C to +125°C

SRT Microcéramique Low Voltage High Capacitance X7T Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 100µF
TCR of +22% -33% with 0Vdc applied
Voltages from 2.5V to 100V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X7T
Operating temperatures of -55°C, + 125°C

SRT Microcéramique SMD Extended Range Low Voltage Capacitors

SMD Low Voltage Capacitors (Extended Range)
Capacitance up to 220 µF
Voltages from 6.3V to 2000V
Operating temperature:
- NP0, X7R: -55°C to +125°C
- X5R: -55°C to +85°C
Tested in accordance with CECC 32100 and AEC-Q200

SRT Microcéramique SMD Low Voltage Class I Capacitors

Low Voltage Class I SMD Capacitor
Capacitance from 0.1 pF to 820 nF
TCR of ± 30ppm with 0Vdc applied
Voltages from 10V to 1000V
Operating temperatures of -55°C to +125°C
Tested in accordance to CECC 32100 and AEC-Q200

SRT Microcéramique SMD Low Voltage Class II Capacitors

Low Voltage Class II SMD Capacitor
Capacitance from 2.2 pF to 47 µF
TCR of ± 15% with 0Vdc applied (X7R) / +15% -25% at rated voltage (BX)
Voltages from 10V to 1000V
Operating temperatures of -55°C to +125°C
Tested in accordance to CECC 32100 and AEC-Q200

SRT Microcéramique SMD Low Voltage N2T Capacitors

Low Voltage N2T SMD Capacitor
Capacitance from 0.3 pF to 1.2 µF
TCR of -2200 ± 350 ppm/°C with 0Vdc applied
Voltages from 10V to 1000V
Operating temperatures of -55°C to +125°C
All PME SMD available in non magnetic termination

Isabellenhütte VMI Series

Current sensing precision resistor
Long sided terminal surface-mount 0805 chip size
Resistance range from 0.01Ω to 0.05Ω
Tolerance of ±5%
TCR from <±30 ppm/°C
Power rating up to 0.5W (at +100°C)
Temperature range from -65°C to +170°C

Isabellenhütte VMI-R000 Series

Zero ohm jumper / Power bridge
Surface-mount design in a 0805 chip size
Resistance value of <200µΩ
TCR of 3200 ±500 ppm/°C
Constant current of up to 35A DC
Power rating of 0.25W (at +170°C)
Temperature range from -65°C to +170°C

Exxelia Ohmcraft SM 0805

High Ohmic SMD Resistors
Resistance range from 10kΩ to 50GΩ
Tolerances from ±0.5% to ±20%
TCR of ±50 ppm/°C, ±100 ppm/°C or ±200 ppm/°C
Power rating of 0.2W
Voltage rating of 125V
Temperature range from -55°C to +150°C

Exxelia Ohmcraft HVC 0805

High Voltage SMD Resistors
Resistance range from 10kΩ to 50GΩ
Tolerances from ±0.5% to ±20%
TCR of ±50 ppm/°C, ±100 ppm/°C or ±200 ppm/°C
Power rating of 0.2W
Voltage rating of 600V
Temperature range from -55°C to +150°C

Exxelia Ohmcraft MCH 0805

Military Grade High Voltage SMD Resistors
Resistance range from 10kΩ to 50GΩ
Tolerances from ±0.5% to ±20%
TCR of ±50 ppm/°C, ±100 ppm/°C or ±200 ppm/°C
Power rating of 0.2W
Voltage rating of 600V
Temperature range from -55°C to +150°C

SRT CBW 0805

Non-magnetic thick film chip resistor
Resistance range from 10Ω to 1TΩ
Tolerances from ±5.0% to ±30%
TCR from ±100 ppm/°C to ±3000 ppm/°C
Power rating of 0.125W (at +70°C)
Temperature range from -55°C up to +155°C

SRT CHM 0805

Non-magnetic thick film chip resistor
Resistance range from 100kΩ to 1TΩ
Tolerances from ±0.5% to ±30%
TCR from ±25 ppm/°C to ±2000 ppm/°C
Power rating of 0.125W (at +70°C)
Temperature range from -55°C up to +155°C

SRT Microcéramique Low Voltage High Capacitance X7R Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 47µF
TCR of ±15% with 0Vdc applied
Voltages from 4V to 100V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X7R
Operating temperatures of -55°C to +125°C **

SRT Microcéramique Low Voltage High Capacitance X5R Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 330µF
TCR of ±15% with 0Vdc applied
Voltages from 4V to 50V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X5R
Operating temperatures of -55°C, + 85°C

SRT Microcéramique Low Voltage High Capacitance X6S Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 330µF
TCR of ±22% with 0Vdc applied
Voltages from 2.5V to 50V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X6S
Operating temperatures of -55°C, + 105°C

SRT Microcéramique Low Voltage High Capacitance X7S Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 100µF
TCR of ±22% with 0Vdc applied
Voltages from 4V to 100V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X7S
Operating temperatures of -55°C to +125°C

SRT Microcéramique Low Voltage High Capacitance X7T Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 100µF
TCR of +22% -33% with 0Vdc applied
Voltages from 2.5V to 100V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X7T
Operating temperatures of -55°C, + 125°C

SRT Microcéramique SMD Extended Range Low Voltage Capacitors

SMD Low Voltage Capacitors (Extended Range)
Capacitance up to 220 µF
Voltages from 6.3V to 2000V
Operating temperature:
- NP0, X7R: -55°C to +125°C
- X5R: -55°C to +85°C
Tested in accordance with CECC 32100 and AEC-Q200

SRT Microcéramique SMD Low Voltage Class I Capacitors

Low Voltage Class I SMD Capacitor
Capacitance from 0.1 pF to 820 nF
TCR of ± 30ppm with 0Vdc applied
Voltages from 10V to 1000V
Operating temperatures of -55°C to +125°C
Tested in accordance to CECC 32100 and AEC-Q200

SRT Microcéramique SMD Low Voltage Class II Capacitors

Low Voltage Class II SMD Capacitor
Capacitance from 2.2 pF to 47 µF
TCR of ± 15% with 0Vdc applied (X7R) / +15% -25% at rated voltage (BX)
Voltages from 10V to 1000V
Operating temperatures of -55°C to +125°C
Tested in accordance to CECC 32100 and AEC-Q200

SRT Microcéramique SMD Low Voltage N2T Capacitors

Low Voltage N2T SMD Capacitor
Capacitance from 0.3 pF to 1.2 µF
TCR of -2200 ± 350 ppm/°C with 0Vdc applied
Voltages from 10V to 1000V
Operating temperatures of -55°C to +125°C
All PME SMD available in non magnetic termination

Isabellenhütte VMI Series

Current sensing precision resistor
Long sided terminal surface-mount 0805 chip size
Resistance range from 0.01Ω to 0.05Ω
Tolerance of ±5%
TCR from <±30 ppm/°C
Power rating up to 0.5W (at +100°C)
Temperature range from -65°C to +170°C

Isabellenhütte VMI-R000 Series

Zero ohm jumper / Power bridge
Surface-mount design in a 0805 chip size
Resistance value of <200µΩ
TCR of 3200 ±500 ppm/°C
Constant current of up to 35A DC
Power rating of 0.25W (at +170°C)
Temperature range from -65°C to +170°C

Exxelia Ohmcraft SM 0805

High Ohmic SMD Resistors
Resistance range from 10kΩ to 50GΩ
Tolerances from ±0.5% to ±20%
TCR of ±50 ppm/°C, ±100 ppm/°C or ±200 ppm/°C
Power rating of 0.2W
Voltage rating of 125V
Temperature range from -55°C to +150°C

Exxelia Ohmcraft HVC 0805

High Voltage SMD Resistors
Resistance range from 10kΩ to 50GΩ
Tolerances from ±0.5% to ±20%
TCR of ±50 ppm/°C, ±100 ppm/°C or ±200 ppm/°C
Power rating of 0.2W
Voltage rating of 600V
Temperature range from -55°C to +150°C

Exxelia Ohmcraft MCH 0805

Military Grade High Voltage SMD Resistors
Resistance range from 10kΩ to 50GΩ
Tolerances from ±0.5% to ±20%
TCR of ±50 ppm/°C, ±100 ppm/°C or ±200 ppm/°C
Power rating of 0.2W
Voltage rating of 600V
Temperature range from -55°C to +150°C

SRT CBW 0805

Non-magnetic thick film chip resistor
Resistance range from 10Ω to 1TΩ
Tolerances from ±5.0% to ±30%
TCR from ±100 ppm/°C to ±3000 ppm/°C
Power rating of 0.125W (at +70°C)
Temperature range from -55°C up to +155°C

SRT CHM 0805

Non-magnetic thick film chip resistor
Resistance range from 100kΩ to 1TΩ
Tolerances from ±0.5% to ±30%
TCR from ±25 ppm/°C to ±2000 ppm/°C
Power rating of 0.125W (at +70°C)
Temperature range from -55°C up to +155°C
