Susumu PAT0510S Series

Product Features

  • High precision chip attenuator
  • Surface mount design with an 0402 chip size
  • Attenuation of 0dB to 10dB (1dB steps)
  • Attenuation tolerance down to ยฑ0.3dB
  • Impedance of 50ฮฉ
  • Temperature range from โˆ’55ยฐC to +125ยฐC
  • Compliant

The PAT0510S high precision chip attenuator is part of the PAT series of thin film attenuators designed for high precision applications from Susumu. The PAT0510S model has a 0402 chip size and is available in an attenuation range of 0dB to 10dB in 1dB steps. This series utilises a similar wrap-around terminal to that of regular chip resistors making them easy to mount. One chip attenuator covers a wide frequency range of up to 10Ghz DC. These attenuators have been developed to withstand operating temperatures between โˆ’55ยฐC to +125ยฐC.

  • High precision chip attenuator
  • Surface mount design with an 0402 chip size
  • Attenuation of 0dB to 10dB (1dB steps)
  • Attenuation tolerances of ยฑ0.3dB, ยฑ0.5dB or ยฑ0.7dB
  • Impedance of 50ฮฉ
  • VSWR of <1.3
  • Operating frequency of DCโˆผ10GHz
  • Rated power of 32mW
  • Temperature range from โˆ’55ยฐC to +125ยฐC
  • Rated operating temperature +70ยฐC

The Susumu PAT0510S high precision chip attenuator is ideal for the following applications:

  • Cell phone base stations
  • Wireless communication modules
  • Wide band measurement instrumentation


Susumu PAT0510S Series Specification Table

AttenuationAttenuation toleranceImpedanceVSWROperating frequencyRated powerPackaging quantity
0 - 3dB (1dB steps)ยฑ0.3dB50ฮฉ (C)<1.3DC~10Ghz32mWT10 (10,000 pcs/reel)
4 - 7dB (1dB steps)ยฑ0.5dB50ฮฉ (C)<1.3DC~10Ghz32mWT10 (10,000 pcs/reel)
8 - 10dB (1dB steps)ยฑ0.7dB50ฮฉ (C)<1.3DC~10Ghz32mWT10 (10,000 pcs/reel)

Susumu is a leading manufacturer of thin-film attenuators, covering a range of attenutations from 0dB to 20dB. Specialised in the production of High precision, High frequency and Thermovariable Attenuators available in various small chip sizes to compliment miniturisation of devices. Please visit www.susumu.co.jp/usa/ for more information.

Specifications

Dimensions 0.25 x 0.50 x 1.00mm
Series / Model

Power Rating

Tolerance

, ,

Operating Frequency

10GHz

Impedance

50ฮฉ

Attenuation

0dB, 1dB, 2dB, 3dB, 4dB, 5dB, 6dB, 7dB, 8dB, 9dB, 10dB

Susumu PAT Series Ordering Info

The PAT attenuator series is available with various options. The information below gives an example of the part numbering system used for these attenuators and the options available.

Below is an example of the part number break down for the PAT attenuator series:

Susumu PAT Series Ordering Information

Product Variations

SKUAttenuationImpedance
Susumu PAT0510S Series0dB50ฮฉ

Request Quote

Susumu PAT0510S Series10dB50ฮฉ

Request Quote

Susumu PAT0510S Series1dB50ฮฉ

Request Quote

Susumu PAT0510S Series2dB50ฮฉ

Request Quote

Susumu PAT0510S Series3dB50ฮฉ

Request Quote

Susumu PAT0510S Series4dB50ฮฉ

Request Quote

Susumu PAT0510S Series5dB50ฮฉ

Request Quote

Susumu PAT0510S Series6dB50ฮฉ

Request Quote

Susumu PAT0510S Series7dB50ฮฉ

Request Quote

Susumu PAT0510S Series8dB50ฮฉ

Request Quote

Susumu PAT0510S Series9dB50ฮฉ

Request Quote
