100µΩ series

  • Resi

Resi SRES6918BL100VST0

High-precision shunt current sensing module with 100µΩ resistance, 400A current rating and ±0.1% accuracy for EV, BMS and energy storage systems.
  • Isabellenhütte

Isabellenhütte BSS Series

Isabellenhütte BSS current sensing shunt resistor with Molex DuraClik connector product image
  • Shunt resistor
  • 8420 Package size
  • Resistance value of 100µΩ
  • Tolerance of ±5.0%
  • TCR of <±50 ppm/°C
  • Power rating of 20W
  • AEC-Q200 qualified
  • Isabellenhütte

Isabellenhütte BAS Series

  • Shunt resistor
  • 8420 package size
  • Resistance range from 35µΩ to 500µΩ
  • Tolerance of ±5.0%
  • TCR from <±50 ppm/°C
  • Power rating of 36W
  • Temperature range from -40°C to +170°C
  • Isabellenhütte

Isabellenhütte BVE Series

  • Current sensing resistor
  • Surface-mount 5930 package
  • Resistance range from 0.0001Ω to 0.003Ω
  • Tolerance ±1.0% and ±5.0%
  • TCR from <±50 ppm/°C
  • Power rating of 15W (at +70°C)
  • Temperature range from -65°C to +170°C
  • Isabellenhütte

Isabellenhütte BVM-F Series

  • Current sensing resistor
  • 3 different terminal types
  • Resistance range from 0.0001Ω to 0.0005Ω
  • Tolerance ±5.0%
  • TCR value <50 ppm/°C
  • Power rating of 5W
  • Temperature range from -55°C to +140°C
  • Isabellenhütte

Isabellenhütte KVM Series

  • Current sensing resistor
  • Resistance values of 100µΩ or 50µΩ
  • Tolerance of ±5%
  • TCR from <50 ppm/°C
  • Power rating of 10W (at 70°C)
  • Temperature range from -55°C to +170°C

Resi SRES6918BL100VST0

High-Precision Shunt Based Current Sensing Module
High-precision shunt current sensing module with 100µΩ resistance, 400A current rating and ±0.1% accuracy for EV, BMS and energy storage systems.

Isabellenhütte BSS Series

Current Sensing Resistor
  • Shunt resistor
  • 8420 Package size
  • Resistance value of 100µΩ
  • Tolerance of ±5.0%
  • TCR of <±50 ppm/°C
  • Power rating of 20W
  • AEC-Q200 qualified

Isabellenhütte BAS Series

Current Sensing Precision Shunt Resistor
  • Shunt resistor
  • 8420 package size
  • Resistance range from 35µΩ to 500µΩ
  • Tolerance of ±5.0%
  • TCR from <±50 ppm/°C
  • Power rating of 36W
  • Temperature range from -40°C to +170°C

Isabellenhütte BVE Series

Current Sensing Precision Resistor
  • Current sensing resistor
  • Surface-mount 5930 package
  • Resistance range from 0.0001Ω to 0.003Ω
  • Tolerance ±1.0% and ±5.0%
  • TCR from <±50 ppm/°C
  • Power rating of 15W (at +70°C)
  • Temperature range from -65°C to +170°C

Isabellenhütte BVM-F Series

Current Sensing Precision Shunt Resistor
  • Current sensing resistor
  • 3 different terminal types
  • Resistance range from 0.0001Ω to 0.0005Ω
  • Tolerance ±5.0%
  • TCR value <50 ppm/°C
  • Power rating of 5W
  • Temperature range from -55°C to +140°C

Isabellenhütte KVM Series

Current Sensing Precision Shunt Resistor
  • Current sensing resistor
  • Resistance values of 100µΩ or 50µΩ
  • Tolerance of ±5%
  • TCR from <50 ppm/°C
  • Power rating of 10W (at 70°C)
  • Temperature range from -55°C to +170°C
