• VPG Foil Resistors

VPG PE Series

  • Ultra-precision 4 terminal shunt resistor
  • Resistance range form 0.5Ω to 500Ω
  • Tolerance from ±0.01% to ±5%
  • TCR of ±2.5 ppm/°C, ±5 ppm/°C or ±15 ppm/°C
  • Power rating of upto 10W (on a heat sink at 70°C)
  • Temperature range from -55°C up to +155°C
  • Compliant
  • Caddock

Caddock MG Standard Range

  • Cylindrical high voltage axial leaded resistor
  • Maximum operating voltage from 600V up to 30kV *
  • Resistance values from 200Ω up to 2GΩ *
  • Tolerances of ±0.1%, ±0.25%, ±0.5% and ±1%
  • TCR as tight as ±80 ppm/°C from -15°C to +105°C
  • Maximum power rating from 0.5W up to 15W *
  • Operating Temperature Range of -55°C to +225°C
* Dependant on selected resistor model
  • Exempt
  • Caddock

Caddock MG -15 Range

  • Cylindrical high voltage axial leaded resistor
  • Maximum operating voltage from 960V up to 48kV *
  • Resistance values from 6.5MΩ up to 2GΩ *
  • Tolerances of ±1% and ±5%
  • TCR as tight as ±80 ppm/°C from -15°C to +105°C
  • Maximum power rating from 0.5W up to 15W *
  • Operating Temperature Range of -55°C to +225°C
* Dependant on selected resistor model
  • Exempt
  • Caddock

Caddock MG Extended Range

  • Cylindrical high voltage axial leaded resistor
  • Maximum operating voltage from 2kV up to 30kV *
  • Resistance values from 600Ω up to 10GΩ *
  • Tolerances of ±1% and ±5%
  • TCR as tight as ±80 ppm/°C from +25°C to +105°C
  • Operating Temperature Range of -55°C to +225°C
  • Maximum power rating from 1.5W up to 15W *
* Dependant on selected resistor model
  • Exempt
  • Caddock

Caddock MS Series

  • Precision high temperature power axial leaded through-hole resistor
  • Maximum operating voltage up to 6kV
  • Maximum operating temperature up to +275°C
  • Utilises Caddock’s Micronox® resistance film for outstanding stability when exposed to a high ambient temperature, thermal shock and high power densities
  • MS resistors have demonstrated excellent long-term stability of 0.05% per 1,000 hours over extended life
  • Caddock’s non-inductive design available on some models
  • Exempt
  • Caddock

Caddock MV Series

  • Low resistance high temperature power axial leaded through-hole resistor
  • Maximum operating temperature up to +275°C
  • Utilises Caddock’s Micronox® resistance film
  • Five sizes and power ratings
  • Utilises Caddock’s non-inductive design
  • Exempt
  • Caddock

Caddock MX500 Series

  • High ohmic high voltage axial leaded through-hole resistor
  • Maximum operating temperature up to +175°C
  • Utilises Caddock’s Micronox® resistance film
  • Five sizes and voltage ratings from 7.5kV up to 32kV
  • Utilises Caddock’s non-inductive design
  • Exempt
  • Coto Technology

Coto CT10 Series

  • Surface mount moulded switch
  • Carry current DC 0.5A (max)
  • Ideal for SMD pick and place
  • Rugged encapsulation
  • Available in gull wing and axial configurations
  • Tape and reel packaging available
  • Temperature range −40°C to +125°C
  • Compliant
  • Isabellenhütte

Isabellenhütte A-H1 Series

  • A-H1 current sense resistor
  • 4-terminal through-hole design
  • Resistance range from 0.001Ω to 100Ω
  • Tolerance of ±0.1% or ±1%
  • TCR of <±30 ppm/°C
  • Power rating of 10W on a suitable heat sink
  • Temperature range from -55°C to +140°C
  • Compliant
  • Isabellenhütte

Isabellenhütte A-H2 Series

  • Current sense resistor
  • 4-terminal through-hole design
  • Resistance range from 0.001Ω to 100Ω
  • Tolerance of ±0.1% or ±1%
  • TCR of <±30 ppm/°C
  • Power rating of 10W on a suitable heat sink
  • Temperature range from -55°C to +140°C
  • Compliant
  • Isabellenhütte

Isabellenhütte AZ-H1 Series

  • Current sensing resistor
  • 4-terminal through-hole design
  • Resistance range from 0.002Ω to 5Ω
  • Tolerance of ±0.1% or ±1%
  • TCR of <±3 ppm/°C or <±10 ppm/°C (+20°C to +60°C)
  • Power rating 10W on a suitable heat sink
  • Temperature range from -55°C to +140°C
  • Compliant
  • Isabellenhütte

Isabellenhütte AZ-H2 Series

  • Current sensing resistor
  • 4-terminal through-hole design
  • Resistance range from 0.002Ω to 1Ω
  • Tolerance of ±0.1% or ±1%
  • TCR of <±3 ppm/°C or <±10 ppm/°C (+20°C to +60°C)
  • Power rating 10W on a suitable heat sink
  • Temperature range from -55°C to +140°C
  • Compliant
  • Isabellenhütte

Isabellenhütte BVE Series

  • Current sensing resistor
  • Surface-mount 5930 package
  • Resistance range from 0.0001Ω to 0.003Ω
  • Tolerance ±1.0% and ±5.0%
  • TCR from <±50 ppm/°C
  • Power rating of 15W (at +70°C)
  • Temperature range from -65°C to +170°C
  • Compliant
  • Isabellenhütte

Isabellenhütte BVN Series

  • Current sensing resistor
  • 4-terminal surface-mount 1216 package
  • Resistance range from 0.0003Ω to 0.003Ω
  • Tolerance ±1.0% or ±5.0%
  • TCR value <50 ppm/°C
  • Power rating 10W (at +70°C)
  • Temperature range from -65°C to +170°C
  • Compliant
  • Isabellenhütte

Isabellenhütte BVR Series

  • Current sensing resistor
  • 4-terminal surface-mount 4026 package
  • Resistance range from 0.0002Ω to 0.003Ω
  • Tolerance ±1.0% or ±5.0%
  • TCR of <20 ppm/°C or <50 ppm/°C
  • Power rating up to 12W (at 70°C)
  • Temperature range from -65°C to +170°C
  • Compliant
  • Isabellenhütte

Isabellenhütte BVS Series

  • Current sensing resistor
  • Surface-mount 3920 chip size
  • Resistance range from 0.0002Ω to 0.003Ω
  • Tolerances of ±1.0% and ±5.0%
  • TCR value from ±50 ppm/°C
  • Power rating up to 12W (at 70°C)
  • Temperature range from -65°C to +170°C
  • Compliant
