Supporting Manufacturer Information

±100 ppm/°C series

  • Isabellenhütte

Isabellenhütte BAS Series

  • Shunt resistor
  • 8420 package size
  • Resistance range from 35µΩ to 500µΩ
  • Tolerance of ±5.0%
  • TCR from <±50 ppm/°C
  • Power rating of 36W
  • Temperature range from -40°C to +170°C
  • Isabellenhütte

Isabellenhütte BRS Series

  • Current sensing resistor
  • 3812 chip size
  • Resistance range from 0.002Ω to 0.025Ω
  • Tolerances from ±1%
  • TCR from ±100 ppm/°C
  • Power rating of 2W (at 120°C)
  • Temperature range from -55°C to +170°C
  • Isabellenhütte

Isabellenhütte BVE Series

  • Current sensing resistor
  • Surface-mount 5930 package
  • Resistance range from 0.0001Ω to 0.003Ω
  • Tolerance ±1.0% and ±5.0%
  • TCR from <±50 ppm/°C
  • Power rating of 15W (at +70°C)
  • Temperature range from -65°C to +170°C
  • Isabellenhütte

Isabellenhütte BVH Series

  • Current sensing resistor
  • 4-terminal through-hole design
  • Resistance values of from 0.0003Ω to 0.0005Ω
  • Tolerance ±3.0% or ±5.0%
  • TCR of <300 ppm/°C
  • Power rating of 5W
  • Temperature range from -55°C to +170°C
  • Isabellenhütte

Isabellenhütte KVM Series

  • Current sensing resistor
  • Resistance values of 100µΩ or 50µΩ
  • Tolerance of ±5%
  • TCR from <50 ppm/°C
  • Power rating of 10W (at 70°C)
  • Temperature range from -55°C to +170°C
  • Isabellenhütte

Isabellenhütte SMK Series

  • Current sensing precision resistor
  • 2-terminal surface-mount design in a 1206 chip size
  • Resistance range from 0.008Ω to 0.5Ω
  • Tolerances of 1% and ±5%
  • TCR from <±50ppm/°C
  • Power rating of 1W (at 110°C)
  • Temperature range -65°C to +170°C
  • Isabellenhütte

Isabellenhütte SMS-PW Series

  • Space approved current sensing precision resistor
  • 2-terminal surface-mount design in a 2512 chip size
  • Resistance range of 0.003Ω to 1Ω
  • Tolerances of ±0.5% and ±1%
  • TCR from ±50ppm/°C (+22°C to +60°C)
  • Power rating of 2W (at +120°C)
  • Temperature range from -55°C to +170°C
  • Isabellenhütte

Isabellenhütte SMT Series

  • Current sensing precision resistor
  • 2-terminal surface-mount 2817 chip size
  • Resistance range from 0.004Ω to 4.7Ω
  • Tolerance range from ±0.5% to ±5%
  • TCR from <±50 ppm/°C
  • Power rating of 5W (at +105°C)
  • Temperature range -65°C to +170°C
  • Isabellenhütte

Isabellenhütte SMT-PW Series

  • Space approved current sensing precision resistor
  • 2-terminal surface-mount design in a 2817 chip size
  • Resistance range from 0.004Ω to 2Ω
  • Tolerances of ±0.5% and ±1%
  • TCR from <±50ppm/°C
  • Power rating of 3W (at +130°C)
  • Temperature range from -55°C to +170°C
  • Isabellenhütte

Isabellenhütte WAK Series

  • Current sensing precision resistor
  • Constant current up to 90A (0.5mΩ)
  • Resistance range from 0.0005Ω and 0.001Ω
  • Tolerances of ±1.0% and ±5.0%
  • TCR of <100 and <130 ppm/K
  • Power rating of 4W (up to 150°C)
  • AEC-Q200 qualified
  • SRT Resistor Technology

SRT CBW 0402

  • Non-magnetic thick film chip resistor
  • Resistance range from 10Ω to 100GΩ
  • Tolerances from ±5.0% to ±30%
  • TCR from ±100 ppm/°C to ±3000 ppm/°C
  • Power rating of 0.05W (at +70°C)
  • Temperature range from -55°C to +155°C
  • SRT Resistor Technology

SRT CBW 0603

  • Non-magnetic thick film chip resistor
  • Resistance range from 10Ω to 100GΩ
  • Tolerances from ±5.0% to ±30%
  • TCR from ±100 ppm/°C to ±3000 ppm/°C
  • Power rating of 0.1W (at +70°C)
  • Temperature from -55°C to +155°C
  • SRT Resistor Technology

SRT CBW 0805

  • Non-magnetic thick film chip resistor
  • Resistance range from 10Ω to 1TΩ
  • Tolerances from ±5.0% to ±30%
  • TCR from ±100 ppm/°C to ±3000 ppm/°C
  • Power rating of 0.125W (at +70°C)
  • Temperature range from -55°C up to +155°C
  • SRT Resistor Technology

SRT CBW 1206

  • Non-magnetic thick film chip resistor
  • Resistance range from 10Ω to 1TΩ
  • Tolerances from ±5.0% to ±30%
  • TCR from ±100 ppm/°C to ±2000 ppm/°C
  • Power rating of 0.25W (at +70°C)
  • Temperature range from -55°C to +155°C
  • SRT Resistor Technology

SRT CDV Series

The SRT CDV Series high‑voltage thick film chip resistor dividers in 2512 and 4020 chip sizes offer R1 values up to 1 GΩ, divider ratios to 1000:1 and maximum working voltages up to 4,000 V. Low TCR options, non‑magnetic variants and a no‑organics design support precise operation in demanding high‑voltage and high‑vacuum applications.
  • SRT Resistor Technology

SRT CHM 0805-HT

  • High temperature, non-magnetic thick film chip resistor
  • Resistance range from 100kΩ to 1TΩ
  • Tolerances from ±2% to ±30%
  • TCR from ±25 ppm/°C to ±2000 ppm/°C
  • Power rating of 0.125W (at +70°C)
  • Temperature range from -55°C up to +300°C
