Subsea

We have worked on many projects in the subsea sector from Christmas trees to subsea sampling skids, ROV’s as well as subsea wellheads for some of the biggest companies in this field. We also have experience in working towards API certifications and can offer many products already qualified to these standards.

  • Core Sensors
  • Non-Clogging submersible pressure transducer
  • Pressure ranges from 2 PSI to 50 PSI
  • Flush diaphragm prevents clogging
  • Hastelloy C276 diaphragm material
  • IP68 rated
  • Operating temperature of -40 to +85°C
  • Compensated temperatures from 0 to +55°C
  • Core Sensors
  • Industrial temperature transmitter
  • RTD sensor type, PT100, Class B
  • Media temperature range of -40°C up to +200°C *
  • Operating temperature range of -40°C up to +85°C
  • Total error at RT & FS of ≤±1%
  • Maximum pressure of 5,000 PSI
  • Amplified 4-20mA or 1-5V output signal
  • Core Sensors
  • Non-Incendive Differential Pressure Transducer
  • Differential pressure up to 50 PSI
  • Line pressure up to 500 PSI
  • Accuracy of ≤±0.25% BFSL / ≤±0.5% BFSL (2 PSI & below)
  • Overpressure of 2X or 500 PSI (whichever is less)
  • Temperature range −40°C to +80°C
  • Media temperature of -40 to +125°C
  • Core Sensors
  • Explosion-Proof Pressure Transducer
  • Pressure ranges from 50 PSI to 30,000 PSI
  • One piece diaphragm design – No internal O-rings or welds
  • Factory sealed stainless steel case – Withstands harsh environments
  • Accuracy of ≤±0.25% BFSL at 25°C (<10,000 PSI)
  • Pressure cycles of 100 million
  • Overpressure of 2x minimum
  • Core Sensors
  • Downhole Pressure Sensor
  • Configurable pressure from 5,000 to 30,000 PSI
  • Accuracy of ≤±0.2% BFSL
  • PT1000 RTD temperature output
  • High strength Inconel 718 (UNS N07718) sensing element
  • Compensated over pressure and temperature
  • Operating Temperature of -40°C to +204°C
  • Paine
  • Differential pressure transducer
  • Very low thermal sensitivity shift of ±0.01% of F.S. per°C
  • Small, lightweight manifold style mounting for easy installation
  • Temperature compensated design provides highly accurate pressure measurements
  • Shock and vibration resistant design offers highly accurate and reliable pressure monitoring in many operating conditions
  • Durable solution withstands harsh environments for long-lasting performance
  • Custom electrical connection and pressure port adaptors are available on request
  • Paine
  • Differential pressure transducer
  • Thermal sensitivity shift of ±0.01% of F.S. per °C
  • Small, lightweight manifold style mounting for easy installation
  • Shock and vibration resistant design offers highly accurate and reliable pressure monitoring in many operating conditions
  • Compact design for an easy-to-use differential measurement solution
  • Durable solution withstands harsh environments for long-lasting performance
  • Custom electrical connection and pressure port adaptors are available on request
  • Paine
  • High pressure and temperature transducer
  • Considered as an ideal solution for downhole, subsea and industrial design
  • Full scale (F.S.) sensitivity of 2.6mV/V ±0.2%
  • External case pressure up to 20,000 PSI
  • All-welded, sealed construction provides durability, resilience and stability in harsh and corrosive environments
  • Non-linearity and hysteresis combined: ±0.15% F.S. max (BSLM)
  • Paine
  • Subsea pressure and temperature transmitter
  • Fully submersible transmitter designed for remote subsea systems for pressure and temperature measurement
  • Resolution of 16 bits minimum (0.08 PSI for 5,000 PSI Full Scale) with digital CANopen® Accuracy
  • Customisable transmitter options available for fit-for-use designs
  • Paine
  • Ultra miniature high pressure transducer
  • Designed for harsh environments
  • Drift less than 0.05% of full scale over 60 days
  • Output at zero pressure of 0.1 mv/v ±0.01 mv/v at 75°F or 23°C
  • Customisable transducer options available for fit-for-use designs
  • Paine
  • High precision pressure and temperature transmitter with programmable temperature Output: °F or °C
  • Withstands harsh and extreme environments for durability in tough applications
  • Customisable transmitter options available for fit-for-use designs
  • Paine
  • Precision pressure and temperature transmitter with a Temperature Output of °F or °C
  • Micro-processor based technology provides precise digital measurements for optimal accuracy and a temperature resolution of 12 Bits minimum
  • Customisable transmitter options available for fit-for-use designs
  • Stellar Technology
  • High capacity miniature tension and compression load cell
  • Shock and vibration resistant
  • Variety of mounting configurations
  • All welded stainless steel construction
  • 5 point calibration record traceable to NIST (0, 50%, 100%, 50%, 0)
  • Temperature effect on zero ±0.005% FSO/°F
  • Temperature effect on span ±0.005% Reading/°F
  • Zero balance ±1% FSO
  • Stellar Technology
  • High accuracy miniature tension or compression load cell
  • Shock and vibration resistant
  • Variety of mounting configurations available
  • All welded stainless steel construction
  • 5 point calibration record traceable to NIST (0, 50%, 100%, 50%, 0)
  • Temperature effect on zero ±0.005% FSO/°F
  • Temperature effect on span ±0.005% Reading/°F
  • Zero balance ±1% FSO
  • Stellar Technology
  • General purpose, high accuracy pancake tension and compression load cell
  • Barometric compensation
  • Shock and vibration resistant
  • Low profile design
  • All welded stainless steel construction
  • 5 point calibration record traceable to NIST (0, 50%, 100%, 50%, 0)
  • Temperature effect on zero ±0.002% FSO/°F
  • Temperature effect on span ±0.002% Reading/°F
  • Zero balance ±1% FSO
  • Stellar Technology
  • General purpose, high accuracy pancake tension and compression load cell
  • Barometric compensation
  • Shock and vibration resistant
  • Low profile design
  • All welded stainless steel construction
  • 5 point calibration record traceable to NIST (0, 50%, 100%, 50%, 0)
  • Temperature effect on zero ±0.002% FSO/°F
  • Temperature effect on span ±0.002% Reading/°F
  • Zero balance ±1% FSO
Please be advised that due to the ongoing supply issues with raw materials affecting the global electronics industry, as well as an increase in orders received by our manufacturing partners, a large number of products are facing increased lead times in recent months. For the latest lead time and stock availability, please contact one of our engineers who will be happy to discuss lead times further and the potential for alternative parts.
