Emerson Paine™ 210-60-090 Series

Emerson Paine™ 210-60-090 Series
Emerson Paine™ 210-60-090 Series
Emerson Paine™ 210-60-090 Series
  • Paine

Product Features

  • Differential pressure transducer
  • Very low thermal sensitivity shift of ±0.01% of F.S. per°C
  • Small, lightweight manifold style mounting for easy installation
  • Temperature compensated design provides highly accurate pressure measurements
  • Shock and vibration resistant design offers highly accurate and reliable pressure monitoring in many operating conditions
  • Durable solution withstands harsh environments for long-lasting performance
  • Custom electrical connection and pressure port adaptors are available on request

Applications

  • Oil & Gas
  • Subsea

Description

The Paine™ 210-60-090 differential pressure transducer series from Emerson offers measuring pressure ranges from ±500 PSID up to ±5000 PSID all in a small size. The 210-60-090 from Emerson is built with two separate sensing elements to measure the pressure at the input ports. This device has a very low thermal shift of ±0.01% of full scale per °C in the toughest environments and provides a differential output along with a uniquely small design. This transducer series is ideal for measuring differential pressure in many applications, such as actuator position feedback from servo valves to automotive and aviation testing environments.

  • Differential pressure transducer
  • Pressure ranges available from ±500 PSID up to ±5000 PSID
  • Compensated temperature −23°C to +121°C
  • Small, lightweight manifold style mounting for easy installation
  • Accuracy of P1=2mV/V ±10% and P2=P1 ±2% of P1
  • Output of mV/V
  • Operating media of any compatible with 300 series CRES, Buna-N-Rubber, 2024-T351 AL and PH CRES
  • Very low thermal sensitivity shift of ±0.01% of F.S. per °C
  • Temperature compensated design provides highly accurate pressure measurements
  • Shock and vibration resistant design offers highly accurate and reliable pressure monitoring in many operating conditions
  • Durable solution withstands harsh environments for long-lasting performance
  • Custom electrical connection and pressure port adapters are available on request



Potential applications for the Paine™ 210-60-090 series include:

  • Test stands and measurements
  • Robotic hydraulic controls
  • Industrial process systems
  • Positioning systems
  • Valve pressure control



Please see below the pressure table for the Paine™ 210-60-090 series, which includes details on standard products available as well as proof and burst pressure ratings:

Paine 210-60-090 Specifications



Specifications

Weight 0.00000 kg
Dimensions 1.88 × 0.70 × 1.15 mm
Series / Model

Output

Temperature Range (°C)

Process Media

Pressure Range

, , , , , , , ,

Emerson Paine 210-60-090 Series Technical Library

We are pleased to provide you with a range of additional content including videos, product datasheets, case studies, white papers and application notes for your reference. Please see below for the latest content available:





DOCUMENTATION
Emerson Paine™ 210-60-090 differential pressure transducer series datasheet
