Caddock MP725 Series

Caddock MP725 power film resistor
Caddock MP725 power film resistor
Caddock MP725 Series
  • Caddock

Product Features

  • D-pak style power surface-mount resistor
  • Low resistance values down to 0.02Ω for current sense applications
  • Non-inductive design
  • Up to 25W power rating at +25°C case temperature
  • Voltage rating of 200V
  • Metal tab assists in post surface-mount soldering inspection
  • Resistor element is electrically isolated from the metal heat sink tab

Applications

  • Power Control
  • Exempt

Description

The MP725 D-Pak style surface-mount power film resistors from Caddock offer a resistance range from 0.02Ω up to 1KΩ and a power rating of up to 25W at +25°C case temperature. The MP725 series tolerance values available are ±1.0%, ±5.0% and ±20.0% (depending on the resistance value required). These resistors introduce Caddock’s proven Micronox® resistance film system in the widely accepted D-Pak style surface-mount power package. The non-inductive design makes this resistor ideal in high frequency communications, power switching circuits, and snubbers.

  • D-Pak style surface-mount power film resistor
  • Resistance values available between 0.02Ω and 1KΩ
  • Metal tab assists in post surface-mount soldering inspection
  • Non-inductive design
  • TCR of 0 to +300 ppm/°C (between 0.02Ω and 0.049Ω), 0 to +200 ppm/°C (between 0.05Ω and 0.49Ω) and -20 to +80 ppm/°C (from 0.5Ω and above)
  • Tolerance of ±5.0% from 0.02Ω to 0.049Ω and ±1.0% from 0.05Ω and 1kΩ (±5.0% and ±20.0% are available for most resistance values)
  • Power rating of up to 25W at +25°C case temperature
  • Maximum voltage rating of 200V
  • Resisor element is electrically isolated from the metal heat sink tab



Use your thermal design experience with power semiconductors in D-Pak style power packages. This experience will help you get the most out of this unique family of surface-mount power resistors. The thermal design issues are the same where power handling capability is based on the case temperature which is maintained in your design.



The below table gives the specifications available for the complete MP725 resistor series:

Caddock MP725 Specifications
* Please see the datasheet for the derating curve.



Specifications

Weight 0.00000 kg
Dimensions 8.13 × 2.79 × 12.32 mm
Minimum Resistance

Series / Model

Maximum Resistance

Temperature Coefficient

, ,

Power Rating

Tolerance

,

Caddock MP725 Series Resources

Product Datasheet

Supporting Product Information

Supporting Manufacturer Information
