Coto RR122-1B92/1B93 Series

coto-tecnology_redrock-tmr-sensors
coto-tecnology_redrock-tmr-sensors
Coto_RR131_SOT-23-3_series
Coto RR122-3C72/3C73 Series
Coto RR122-3C72/3C73 Series
Coto RR122-3C72/3C73 Series
Coto LGA-4 Package Dimensional Diagram
  • Coto Technology

Product Features

  • TMR digital push-pull magnetic sensor
  • Operate sensitivity of 30 G (typical)
  • Average supply current of 36μA at 3V (typical)
  • Supply voltage range of 1.7V to 5.5V
  • Omnipolar push-pull response
  • Operating frequency of 10Hz
  • SOT-23-3 (511) or LGA-4 (512) package

Applications

  • Compliant

Description


The RedRock™ RR122-1B92/1B93 sensor series from Coto Technology is a range of digital push-pull magnetic sensors designed using a patented Tunneling Magnetoresistance (TMR) technology with seamless CMOS integration. The RR122-1B92/1B93 series features a typical operate sensitivity of 30 G (30mT), with an omnipolar magnetic field response. They offer a wide supply voltage range from 1.7V to 5.5V, ideal for applications ranging from small battery-powered electronics to industrial machinery. The TMR sensors have a typical current drain of 36μA (at 3V and operating at 10Hz), and are available with operating temperature ranges of -40°C to +85°C (RR122-1B92-511 & RR122-1B92-512) or -40°C to +125°C (RR122-1B93-511 & RR122-1B93-512). These sensors are ideal for use in medical, industrial, automotive, and consumer applications. All of the RR122-1B92/1B93 series is available in either SOT-23-3 (511 variant) or LGA-4 packages (512 variant).

  • TMR digital push-pull magnetic sensor
  • Operate sensitivity of 30 G (typical)
  • Release sensitivity of 20 G (typical)
  • Average supply current of 36μA at 3V (typical)
  • Supply voltage range of 1.7V to 5.5V
  • Omnipolar push-pull response
  • Operating frequency of 10Hz
  • Temperature range of -40° to +85° (RR122-1B92-511/512)
  • Temperature range of -40°C to +125°C (RR122-1B93-511/512)
  • Hysteresis (BHYST)2 of 10G (typical)
  • SOT-23-3 (511) or LGA-4 (512) package

Approvals for the Coto Technology RR122-1B92/1B93 Series include:

  • RoHS
  • REACH

Typical applications for the Coto Technology RR122-1B92/1B93 Series include:

  • Proximity Detection
  • Rotary Sensing
  • Fluid Level Detection
  • Door & Lid Closure Detection
  • Utility Meters
  • Portable Medical Devices
  • Motor Controllers
  • Consumer Electronics
  • Wake-Up Microprocessor
